Optimization of DVG850 Dual-Screw Worktable System Based on ANSYS Workbench

Abstract:

In traditional single-screw worktable system, the system is always subjected with torque because the driving force and force-bearing point of the workpiece always change with the processing path, so its performance may be affected. Therefore, the scheme of dual-screw worktable system is put forward and modal analysis with ANSYS Workbench is made by taking DVG850 high-speed vertical machining center worktable system for example. Then four alternatives of the machine are proposed based on the position of screw and guide.Through modal analysis of different parameters of the system, we ultimately select the dual-screw worktable system with highest performance (Screws place inside of the guide and horizontal distance of the two screws is 310mm.) as the optimalizing plan. This provides a reliable reference for further study on dynamic analysis of worktable system.

• Periodical: Advanced Materials Research (Volume 601)
• Pages: 181-185
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.601.181
• Online since: December 2012
• Authors: Jiang Miao Yi, Dong Qiang Gao, Fei Zhang, Huan Lin
• Keywords: ANSYS, Dual-Screw Transmission, Modal Analysis, Worktable System

References

[1] Yang Shu-kai, Zhu Qi-xi, Wu Shi-bin. Study on FEM-Based Topological Optimization Design of Brackets [J]. Automobile technology, 2006(3): 16-18.

[2] Fu Zhong-yu, Yang Xiao-jing. Modal Analysis of Leading Screw Based on ANSYS Software. Machinery manufacturing and research, (2004).

[3] Yao Ping, Yao Hong, Wang Xiao-jun, Su Jian-wen. Static and Dynamic Analysis and Optimization of CNC Lathe Bed [J]. Coal Mine Machinery, 2009, 30(2): 208-210.

[4] Wu Ke-long. Solidworks 2009 the Basic and Typical Examples of Machinery, Sheet Metal, Welding in Chinese Version [M]. Electronic Industry Press, (2010).

[5] Hu Yu-jin, Wang Zhang-qi. Analysis and Application of Finite Element [M]. Tsinghua University Press, (2009).

[6] Chen Hua-sheng. Finite Element Analysis and Optimization on Structure of High-speed CNC Gear Milling Machine [D]. Nanjing University of Technology, (2005).

[7] Gao Dong-qiang, Tian Zhen-ya, Hao Da-jian, Yao Su-fen. The analysis and study of dynamic characteristics of screw Based on ANSYS [J]. Hoisting and conveying machinery, 2008(11), 54-57.

[8] GAO Dong-qiang, MAO Zhi-yun, ZHANG Gong-xue, LI Zhong-yan. The Static and dynamic Characteristic Analysis and Structure Improvement of DVG850 Worktable [J]. Machinery Design and Manufacture, 2011(3), 146-147.
