Stress Analysis of a 600 MW Supercritical Boiler Start-Up Separator in Peak Load Operation

Abstract:

Taking a start-up separator of 600 MW supercritical boiler as the study object, analyse the stress field of it during the process of load pick-up with the three-dimensional finite element analysis method. In the analytical process, it has calculated the thermal stress, mechanical stress and the total stress of them, and analysed the change rules of them, so it provide the guidance of the production operation processes. The calculation results show that: the thermal stress of open pore on start-up separator exists obvious stress concentration phenomenon; The stress concentration of the total stress occurred in the oval long axis of cylinder body wall, where is the danger point of the start-up separator.

• Periodical: Advanced Materials Research (Volume 601)
• Pages: 149-157
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.601.149
• Online since: December 2012
• Authors: Hong Dou, Qiang Zhang, Yuan Dai, Zhong Guang Fu, Dong Yi Li, Yuan Jing
• Keywords: Finite Element Analysis (FEA), Start-Up Separator, Supercritical Boiler, Thermal Stress

References

[1] Liu Tong, Shi Fei, Sun Bao-min, Huang Qi-li: Journal of Power Engineerin, Vol. 27 (2007) No. 6, p.869.

[2] Li Bin, He Lin-bo, Li Jian-wei: Power System Engineering, Vol. 26 (2010) No. 6, p.16.

[3] Wang Hai-feng, Sang Zhi-fu: China Petroleum Machinery, Vol. 33 (2005) No. 11, p.11.

[4] Wang Ding-biao, Wei Xin-li; Xiang Sa: China Petroleum Machinery, Vol. 34 (2006) No. 4, p.5.

[5] D. Gandy. The Grades 11 and 12 Low Alloy Steel Handbook (Electeric power research institute , American 2007).

[6] Wang Ze-jun: The Boiler Structure Finite Element Analysis (Chenical Industry Press, China 2005), p.113.

[7] Liu Tong: Life Estimation and On-line Monitoring for Pressurte-bearing Part of Utility Bolier (Ph.D., North China Electric Power University, China 2007).

[8] J.C.M. Yu, W.A. Shaw: Second International Conference on Pressure Vessel Technology (San Antonio, Texas, 1973), No. 1-9.

[9] P. Stanley, B.V. Day: Second International Conference onPressure Vessel Technology (San Antonio, Texas, 1973), No. 1-12.

[10] ASME Boiler and Pressure Vessel Code, Section III, Division 1. (American Society of Mechanical Engineers, American 1998).
