Research and Develop on Static Frequency Converter of Pumped Storage Power Plant

Abstract:

A static frequency converter start-up control strategy for pumped-storage power unit is presented. And rotor position detecting without position sensor is realized according to voltage and magnetism equations of ideal synchronous motor mathematics model. The mechanism and implementation method of initial rotor position determination and rotor position estimation under low frequency without position sensor are expounded and validated by simulations. Based on the mentioned control strategy, first set of a static frequency converter start-up device in China for large-scale pumped-storage unit is developed, which is applied to start-up control test in the 90 MW generator/motor of Panjiakou Pumped-storage Power Plant. Test results show that rotor position detecting, pulse commutation, natural commutation, and unit synchronous procedure control of static start-up are all proved. The outcomes have been applied in running equipment, which proves the feasibility of mentioned method.

• Periodical: Advanced Materials Research (Volumes 608-609)
• Pages: 1120-1126
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.608-609.1120
• Online since: December 2012
• Authors: De Shun Wang, Bo Yang, Lian Tao Ji
• Keywords: Pumped Storage Power Plan, Rotor Position Detecting, Sensor Less, SFC

References

[1] G. Magsaysay et al., Use of a Static Frequency Converter for Rapid Load Response in Pumped-Storage Plants, IEEE Trans. on Energy Conversion, Vol. 10, No. 4, December 1995, pp.694-699.

DOI: 10.1109/60.475841

[2] Chiang et al., Mitigation of harmonic disturbance at pumped storage power station with static frequency converter. IEEE Transactions on Energy Conversion. Vol.123,i3. 1996,pp.617-624.

DOI: 10.1109/60.629708

[3] Donalek PJ. Role and value of hydro and pumped storage generation in a proposed regional electricity market in Southeast Europe. In: IEEE power engineering society general meeting, vol. 1; 2003. p.395–398.

DOI: 10.1109/pes.2003.1267207

[4] PETERSSON T．Starting of large synchronous motor using static frequency converter [J]．IEEE Trans PAS,1972, 91(1),P172-179.

DOI: 10.1109/tpas.1972.293328

[5] Wang Deshun; Sang Bingyu; Yang Bo et al.,Research on Static Start-up Control Technology for Gas-Steam Combined Cycle Unit[J] . Power and Energy Engineering Conference 2010, pp.167-171.

[6] Feng Wang, Jianguo Jiang. A novel static frequency converter based on multilevel cascaded H-bridge used for the startup of synchronous motor in pumped-storage power station [J]. Energy Conversion and Management 2011(52), p.2085–(2091)

DOI: 10.1016/j.enconman.2010.12.018

[7] GAO Jingde, WANG Xiangheng, LI Fahai, AC motor and systematic analysis. Stinghua University Press [M]. 1993, P64-80. (CH)

[8] Matthew J. Corley and Robert D. Rotor Position and Velocity Estimation for a Salient-Pole Permanent Magnet Synchronous Machine at Standstill and High Speeds [J]. IEEE Transactions on Industry Applications, 1998,34(4), P784-789.

DOI: 10.1109/28.703973

[9] Alfio Consoli, Giuseppe Scarcella, Antonio Testa, A new zero-frequency flux-position detection approach for Direct-Field-Oriented-Control drives [J], IEEE Trans. Ind. Applicat., 2000,36(3), P797-804.

DOI: 10.1109/28.845055

[10] H. RASMUSSEN.Sensorless speed control including zero speed of non salient PM synchronous drives[J]. Bulletin of The Polish Academy of Sciences Technical Sciences. 2006,54(3), P293-298.

[11] J Davoine et al．Operation of a Self-controlled synchronous motor without a shaft position sensor．IEEE Trans on Industry Applications, 1983, 19(2), P217-222.

DOI: 10.1109/tia.1983.4504184

[12] Hirofumi Akagi.Large Static converters for industry and utility applications [J].Proceedings of The IEEE,2001,89(6), P976-P983.
