Internet of Things Based Auxiliary Control System for Smart Substation

Abstract:

In order to solve the present situation that auxiliary facilities in substation separate from each other and unable to achieve intelligent interactive features, this paper presents the smart substation auxiliary control system based on the IoT (Internet of Things). The system monitors and controls the production auxiliary system of substation, and in the background using IEC61850 communication protocol to achieve the auxiliary production system internal and mutual coordination linkage and information remote transmission. The system integrates all the substation auxiliary facilities, including video monitoring subsystem, security subsystem, lighting subsystem, power supply subsystem and auxiliary system optimal control subsystem, providing smart substation of informatization, automation and interaction auxiliary support.

• Periodical: Advanced Materials Research (Volumes 614-615)
• Pages: 1790-1795
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.614-615.1790
• Online since: December 2012
• Authors: Jia Hui Wang, Xiang Zhen Li, Rui Ting Lu, Feng Jie Sun
• Keywords: Auxiliary Control, Internet of Things (IOT), Monitor, Smart Substation

References

[1] Huansheng Ning, Ziou Wang: Future Internet of Things Architecture: Like Mankind Neural System or Social Organization Framework? Communications Letters, IEEE, Vol.15, Issue.4, pp.461-463, Apr, 2011.

DOI: 10.1109/lcomm.2011.022411.110120

[2] ITU: The Internet of Things, ITU International Reports, 2005.

[3] EPCglobal: The EPCglobal Architecture Framework (final version 1.3, 2009).

[4] Hao Jia, Zhe Wang: The Internet of things technology in substation auxiliary system, Electric Power Science and Engineering, Vol.27, No.4, Apr, 2011.

[5] Yangang Ma, Junzhou Liu: Research and realize of conversion between auxiliary system protocol and IEC 61850 in Smart Substation, Power and Energy Engineering Conference (APPEEC), 2011 Asia-Pacific, 25-28 March 2011, pp.1-4.

DOI: 10.1109/appeec.2011.5748852

[6] Jing Ma, Tong Wang, Jie Wu, and Zengping Wang: Integration of Protection and Control Systems for Smart Substation, Critical Infrastructure (CRIS), 2010 5th International Conference, 20-22 Sept. 2010, pp.1-5.

DOI: 10.1109/cris.2010.5617481

[7] SGCC: Technical guide for smart substation, Q/GDW 383-2009.

[8] Xiangzhi Liu, Jianxin Lou, Qingfeng Zheng, et al, Design and implementation of Behavior identifying functions in substation video monitoring system, Automaton of Electric Power System, 2010, Vol.34, pp.117-119.
