Study of the Wheel of Abrasive Belt Based on Forming Polishing Technology

Abstract:

The wheel of abrasive belt is a special-shaped coated abrasive which has the advantage of good polishing quality, long life, and high efficiency, low cost and so on. Base on the features of the wheel of abrasive belt, through analyzing the basic motion relation of forming polishing spiral surface screw, the wheel of abrasive belt’s profile shape curve could be calculated by establishing the contact line equation of screw spiral surfaces with the wheel of abrasive belt rotating surfaces. Software to verify the correctness of the profile shape calculated, and in accordance with the wheel of abrasive belt profile shape curve to programming NC program. Start with the dressing experiments of the wheel of abrasive belt. Through analysis and research to get the wheel of abrasive belt’s profile shape curve meet the forming polishing standard.

• Periodical: Advanced Materials Research (Volume 619)
• Pages: 249-252
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.619.249
• Online since: December 2012
• Authors: Ke Wang, Zheng Qing Zhao, Xing Wei Sun
• Keywords: Polishing, Screw, Spiral Surface, Wheel of Abrasive Belt

References

[1] K. Wang, A.Q. Zang and X.W. Sun: Polishing of the spiral surfaces screw, Compressor Technology, 2009(4), pp.34-36.

[2] R.S. Lu, Z.H. Shen, Computing and simulation of the profile of grinding wheel grind screw rotor, Journal of Xiamen University, 2011(5), pp.852-855.

[3] Ted Giese, Grinding's future 15 something to be held, Tooling & Production, 1997(6), pp.59-65.

[4] J.J. Wei, K. Wang and X.W. Sun, Analysis on the wheel of abrasive belt polishing mechanism to helix curved surface, CINC, (2010).

DOI: 10.1109/cinc.2010.5643875
