The Control System Design of Newtextile Machine

Abstract:

It is well-known that China is a textile production and export country, especially in Zhejiang and Hangzhou province, the textile industry is well-developed with tremendous amount of application of textile machinery. This paper is about the design of rapier textile machinery with programmable logic controller, including five major functions: opening weft, leading weft, fighting weft, warping and coiling off weft. It has accomplished the function of detecting a broken weft while leading weft, while the signal of detecting is completed by store, and the function of broken warp while warping. PLC Programmer of S7200 Siemens CPU224 is used.
