Flow Stress Determination of Steel Tube for Hydroformability Evaluation

Abstract:

This study aims to determine flow stress of a steel tube by using hydraulic bulge test. A new proposed analytical model for analyzing bulge shapes of hydroformed tubes is postulated. Bulge test apparatus designed using FEA simulation of hydroforming and STKM 11A steel tubes are used in the hydraulic bulge test. Bulge heights and internal pressures are measured during bulge testing. Tube thicknesses at vertex of a bulge shape are measured by a dial caliper gauge. Bulge curvatures and contact points are measured by taking digital photos of bulge shapes combined with measurement methods in CAD software. Effective stress - strain relationships are obtained from the newly developed analytical model using those measured values. Flow stress curves obtained from the effective stress – strain relationships are compared with those by other researchers and tensile test. Finite element analysis methods are used to conduct simulation of tube hydroforming using the flow stress curves. Predicted internal pressures versus bulge heights and tube thicknesses are compared with experimental results. Verification of the developed analytical model is presented. The flow stress at neck point of formed tube is determined.

You might also be interested in these eBooks

Manufacturing Science and Technology III

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 622-623)

Pages:

656-660

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.622-623.656

Citation:

Cite this paper

Online since:

December 2012

Authors:

P. Boonpuek, S. Jirathearanat, N. Depaiwa

Keywords:

Flow Stress Curve, Free Bulge Test, Tube Hydroforming

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] S. Fuchizawa, M. Narazaki: Analysis of bulge deformation of thin tube with cylindrical die – hydrostatic tube bulging with closed die I, Journal of Japan Society for Technology of Plasticity 30 (1989), p.116.

Google Scholar

[2] Muammer Koç, Yingyot Aue-u-lan, Taylan Altan : On the Characteristics of Tubular Materials for Hydroforming - Experimentation and Analysis, International Journal of Machine Tools & Manufacture, 41 (2001), p.761–772.

DOI: 10.1016/s0890-6955(00)00070-5

Google Scholar

[3] Y.M. Hwang, Yi-Kai Lin, T. Altan: Evaluation of tubular materials by a hydraulic bulge test, Journal of Machine Tools & Manufacture 47 (2007), pp.343-351.

DOI: 10.1016/j.ijmachtools.2006.03.009

Google Scholar

[4] Annual Book of ASTM Standards (section 3), 03. 01, 1993, p.60.

Google Scholar
