Flow Field Analysis of Valve Plate for Hot Blast Valve

Abstract:

The valve plate of the hot blast valve is to rely on itself spiral waterway to cool. In the course of actual use, there is uneven actuality that it is cold and hot for the Valve plate of the hot blast valve. In this article, by means of COSMOSFloworks software, based on classic formula for convective heat transfer of heat transfer, we do flow field analysis for the waterway of the valve plate of DN1800 hot blast valve for certain Heavy Industry Group of our country. And analytical result indicates: Uneven distribution of water velocity in the valve plate is an important reason for causing unequal heat exchange of the valve plate and local thermal shock. In order to improve cooling uniformity, the central flow state of the type valve Plate should be altered and water cooling structure of inner water ring edge should be widen, finally the increase of the life of the valve plate can be reached.

• Periodical: Advanced Materials Research (Volume 628)
• Pages: 523-527
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.628.523
• Online since: December 2012
• Authors: Ling Ling Li, Guang Pu Xu, Zhen Dong Su, Yong Ling Kang
• Keywords: Flow Field, Hot Blast Valve, Valve Plate

References

[1] Jingmin Huang, Yili Lin, SolidWorks2009 Senior Design, Beijing, tsinghua university press, pp.450-462, In Chinese.

[2] Yuanyi Liu, Yumin Yuan, Zongwen Miao, Practice of improving hot blast valve lifetime of Laiwu Steel, Ironmaking, 1998, 17（2）: 4, In Chinese.

[3] Zepei Ren, Fengning Mei, Heat Transfer, China architecture and building press, Beijing, 1993, In Chinese.

[4] Guangsheng Du, Engineering Fluid Mechanics, China electric power press, Beijing 2006, pp.120-127, In Chinese.
