Microstructure and Mechanical Properties of Metal Injection Molded SiC_P/ Cu Composites

Abstract:

SiC_P/Cu composite was prepared by metal injection molding process. Microstructure, mechanical properties, fracture surface, and wear resistance of SiC_P/Cu composite were investigated in this study. The research results show that SiC_P/Cu were sintered sucessfully by the sintering process with hydrogen protection and high temperature of 1050°C. The tensile strength of the composites depends on the fraction and distribution of SiC particles which is resulted from microcracks nucleate in the matrix between SiC particles because of SiC particle aggregation. The tensile strengths of 5vol.%, 10vol.%, and15vol.%SiC_P/Cu are 254MPa, 291MPa and 278MPa separately. SiC particles are contribute to enhance the abrasive resitance of the composite when particle volume fraction increase from 10% to 15%.

You might also be interested in these eBooks

Material Sciences and Manufacturing Technology

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 629)

Pages:

105-109

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.629.105

Citation:

Cite this paper

Online since:

December 2012

Authors:

Yi Qiang He, Jian Ming Yang, Bin Qiao, Li Chao Feng

Keywords:

Mechanical Property, Metal Injection Molding (MIM), Microstructure, SiC_p/Cu Composite, Wear Resistance

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] German RM. Scientific status of metal powder injection moldin. International Journal of Powder Metallurgy 2000; 36: 31-6.

Google Scholar

[2] Hauck P. Powder injection molding current and long term outlook. International Journal of Powder Metallurgy 2000; 36: 29-30.

Google Scholar

[3] Qiao B, Shang F, Ding M, Li HQ, He YQ, Yang JM. Process of 316L stainless steel coarse powder by Injection Molding. Journal of aeronautical materials 2010; 30: 30-5.

Google Scholar

[4] Ye HZ, Liu XY, Hong HP. Fabrication of matal matrix composites by metal injection molding-A review. Journal of materials processing technology 2008; 200: 12-24.

DOI: 10.1016/j.jmatprotec.2007.10.066

Google Scholar

[5] Zhang R, Gao L, Guo J. Effect of Cu2O on the fabrication of SiCP/Cu nanocomposites using coated particles and conventional sintering. Composites: Part A 2004; 35:1301-5.

DOI: 10.1016/j.compositesa.2004.03.021

Google Scholar

[6] Celebiefe GF, Altinsoy I, Ipek M, Zeytin S, Bindal C. Some properties of Cu–SiC composites produced by powder metallurgy method. Kovove Mater 2011; 49: 131-6.

DOI: 10.4149/km_2011_2_131

Google Scholar

[7] Zhu J, Liu L, Zhao H, Shen B. Microstructure and performance of electroformed Cu/nano-SiC composite. Materials and Design 2007; 28: 1958–62.

DOI: 10.1016/j.matdes.2006.04.021

Google Scholar

[8] Zhang R, Gao L, Guo J. Temperature-sensitivity of coating copper on submicron silicon carbide particles by electroless deposition in a rotation flask. Surf Coat. Technol 2003;166: 67–71.

DOI: 10.1016/s0257-8972(02)00748-x

Google Scholar

[9] Bose A. Net shaping concepts for tungsten alloys and composites. Powder Metall 2003; 46: 121–6.

Google Scholar

[10] Sapate SG, Uttarwar A, Rathod, RC, Paretkar RK. Analyzing dry sliding wear behaviour of copper matrix composites reinforced with pre-coated SiCP particles. Materials and design 2009; 30: 376-86.

DOI: 10.1016/j.matdes.2008.04.055

Google Scholar

[11] Zhu JH, Liu L, Zhao HJ, Shen B, Hu WB. Microstructure and performance of electroformed Cu/nano-SiC composite. Materials and design 2007; 28: 1958-62.

DOI: 10.1016/j.matdes.2006.04.021

Google Scholar

[12] Zhang L, He XB, Qu XH, Duan BH, Lu X, Qin ML. Dry sliding wear properties of high volume fraction SiCP/Cu composites produced by pressureless infiltration. Wear 2008; 265: 1848-56.

DOI: 10.1016/j.wear.2008.04.029

Google Scholar
