Electric Polarization Characteristic and Equivalent Circuit of the Pb(Zr_0.95Ti_0.05)O₃ Nanoceramics

Abstract:

In this paper, the PZT nano-ceramics were prepared by an improved Sol-Gel method. This method was based on recording to A.S.Mischenko. TF Analyzer 2000 FE was used to measure the ferroelectric properties of the samples. The results show the change trends of the P-E hysteresis loops in different voltages, temperatures and frequencies. Impedance was tested by precision impedance analyzers 6500 series. With the use of the equivalent circuit to simulate the piezoelectric ceramic vibrator we can get a conclusion that in the 85 MHz-120 MHz the response of the sample can be represented with a RLC series resonant circuit. The resonant frequency of the sample is 97.12MHz, and the loss is very low. Compared with the general piezoelectric vibrator PZT 95/05 nano-ceramic is a low frequency capacitor with the capacitance tend to 0 F.

• Periodical: Advanced Materials Research (Volume 629)
• Pages: 309-313
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.629.309
• Online since: December 2012
• Authors: Yuan Yuan Chi, Chao Zhang, Ying Wang, Da Shu Yu
• Keywords: Equivalent Circuit, P-E Hysteresis Loop, Piezoelectric Vibrator, PZT

References

[1] A.S. Mischenko, Q. zhang, et al. Giant Electrocaloric Science. 311. 2006: 1270-1271.

[2] Wang L , Yu J, Wang Y , et al. Effect of Excess Pb in PbTiO3 Precursors on Ferroelecture and Fatigue Property of Sol-gel Derived PbTiO3/PbZr0. 3Ti0. 7O3 Thin Films[J]. Journal of Materials Science: Materials in Electronics, 2008, 19 (12): 1191-1196.

DOI: 10.1007/s10854-007-9524-x

[3] He G, Iijima T, Funakubo H. Combinatorial Preparation Process of Pb(Zr1-xTix)O3 Thin Films by Chemical Solution Deposition Method[J]. Journal of the Cermic Society of Japan, 2009. 117(1365): 698-702.

DOI: 10.2109/jcersj2.117.698

[4] Heng Chang Nie, Xue Feng Chena, Ning Bo Feng, Gen ShuiWang, Xian Lin Dong, Yan Gub, Hong Liang He, Yu Sheng Liu. Effect of external fields on the switching current in PZT ferroelectric ceramics[J]. Solid State Communications. 2010, 150 (1-2): 101-103.

DOI: 10.1016/j.ssc.2009.09.042

[5] Zhang Liangying, Yao Xi. Dielectric physics [M]. Xi'an Jiaotong University Press, 1991: 203-207, 433; [in Chinese].

[6] Zhong Weilie. Ferroelectric physics[M]. Science Press, 1996: 342-385; [in Chinese].

[7] Zhang Peilin, Zhang Zhongyuan. Piezoelectric measurement [M]. Beijing : national defence industry Press, 1983, 25-26.

[8] XP Li, JS Vartuli, DL Milius, IA Aksay, WY Shih, WH Shih. Electromechanical Properties of a Ceramic d31 –Gradient Flextensional Actuator [J]. J. Am. Ceram. Soc., 2001, 84.

DOI: 10.1111/j.1151-2916.2001.tb00781.x

[5] 996–1003.
