Research on the Flow Boiling Characteristics of Water in a Multi-Furcated Tree-Shaped Mini-Channel

Abstract:

A new multi-furcated structure of tree-shaped mini-channel was proposed in this paper. Numerical simulation was conducted to analyze the flow boiling and bubble growth characteristics of water in the mini-channel. By using the constant wall temperature heating method, the model was divided into different sub-regions according to different wall temperatures. Typical bubbly flow and slug flow patterns were obtained through the monitoring of the boiling process. The simulation results showed that when the convective heat transfer dominated, the pressure drop maintained minor and stable; while the nucleate boiling dominated, the pressure drop increased significantly and fluctuated within a certain range. Moreover, with the increase of vapor quality, the heat transfer coefficient increased first and then decreased. It is also found that the geometric structure of the multi-furcated tree-shaped mini-channel had a great impact on the heat transfer characteristics, and simulation results agreed well with the theoretical values.

• Periodical: Advanced Materials Research (Volume 629)
• Pages: 691-698
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.629.691
• Online since: December 2012
• Authors: Chen Yan, Chang Wei, Shu Sheng Zhang
• Keywords: Flow Boiling, Multi-Furcated, Three Dimensional Simulation, Tree-Shaped Mini Channel

References

[1] TUCKERMAN D B, PEACE R F W. High-performance heat sinking for VLSI[J]. IEEE Electron Device Letters, 1981, 2(5): 126-129.

DOI: 10.1109/edl.1981.25367

[2] KANDLIKAR S G. Fundamental issues related to flow boiling in minichannels and microchannels[J]. Experimental Thermal and Fluids Science, 2002, 26(2): 389-407.

DOI: 10.1016/s0894-1777(02)00150-4

[3] HETSRONI G, MOSYAK A, POGREBNYAK E, et al. Heat transfer in micro channels: Comparison of experiments with theory and numerical results[J]. International Journal of Heat and Mass Transfer, 2005(48): 5580-5601.

DOI: 10.1016/j.ijheatmasstransfer.2005.05.041

[4] BEJAN A. ERRERA M R. Deterministic tree networks for fluid flow: geometry for minimal flow resistance between a volume and one point[J]. Journal on the Complex Geometry, 1997, 5(4): 685-695.

DOI: 10.1142/s0218348x97000553

[5] KEARNEY M M. Engineered Fractals enhance process applications[J]. Chemical Engineering Progress, 2000, 96(12): 61-68.

[6] BEJAN A. Constructal-theory network of conductiong paths for cooling a heat generating volume[J]. International Journal of Heat and Mass Transfer, 1997, 40(4): 799-811.

DOI: 10.1016/0017-9310(96)00175-5

[7] ZHANG C B, CHEN Y P, WU R, et al. Flow boiling inconstructal tree-shaped mini-channel network[J]. International Journal of Heat and Mass Transfer, 2011, 54(1-3): 202-209.

DOI: 10.1016/j.ijheatmasstransfer.2010.09.051

[8] PENCE D V. Improved thermal efficiency and temperature uniformity using fractal-like branching channel networks[A]. Proceedings of the International Conference on Heeat Transfer and Transport Phenomena in Micro Scale. Banff, Canada, Begell House, 2000: 142-148.

DOI: 10.1615/1-56700-150-5.180

[9] LIN Ruitai. Boiling heat transfer [M]. Beijing: Science Press, (1988).

[10] YUAN M H, YANG Y H, LI T S, et al. Numerical simulation of film boiling on a sphere with a volume of fluid interface tracking method[J]. International Journal of Heat and Mass Transfer, 2008, 51(7): 1646-1657.

DOI: 10.1016/j.ijheatmasstransfer.2007.07.037

[11] LEE W H. A pressure iteration scheme for two-phase flow modeling[M]. In: Multiphase Tranport Fundamentals, Reactor Safety, Applications, Vol. 1, veziroglu TN (ed. ), Washington, DC: Hemisphere Publishing, (1980).

[12] TANG Chuanyi. The relationship between water and surface tension[J]. Journal of Anqing Teachers College (Natural Science), 2000, 6(1): 73-74.

[13] TALEBI S, ABBASI F, DAVILU H. A 2D numerical simulation of sub-cooled flow boiling at low pressure and low flow rates[J]. Nuclear Engineering and Design, 2009, 239(1): 140-146.

DOI: 10.1016/j.nucengdes.2008.09.007

[14] GUO Lei, ZHANG Shusheng, CHEN Yaqun, et al. Study on bubble dynamics of boiling in vertical rectangular mini-channel. Journal of Xi'an Jiaotong University, 2010, 44(11): 12-17.

DOI: 10.1109/cctae.2010.5544822

[15] SUMITH B, KAMINAGA F, MATSUMURA K. Saturated flow boiling of water in a vertical small diameter tube. Experimental Thermal and Fluid Science, 2003, 27(7): 789-801.

DOI: 10.1016/s0894-1777(02)00317-5
