Design and NC Manufacturing of Plastic Injection Mold Based on UG Software

Abstract:

On the platform of the UG Software’s CAD/MoldWizard/CAM components, the whole process of design and NC manufacturing of the plastic injection mold of a hair dryer’s shell was completed. The CAD/CAM process of the plastic injection mold was introduced by the practical application. The large advantage of the UG platform over the traditional method in the field of plastic injection molds’ design and manufacturing was reflected. The plastic injection molds’ design and manufacturing is a great challenge to the traditional design and manufacturing method, and the UG solutions can promote mold manufacturers’ ability of design and manufacturing remarkably.

• Periodical: Advanced Materials Research (Volume 630)
• Pages: 163-166
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.630.163
• Online since: December 2012
• Authors: Shan Li, Liang Xu, Yu Qi Wang
• Keywords: CAD/CAM, MoldWizard, Plastic Injection Mold, UG

References

[1] Committee of technology of design and manufacturing of mold education series. Structure Design of Mold. Beijing: China Machine Press, 2004. (In Chinese).

[2] Wang G X, Li C G. UG NX 5. 0 Technology Guide of Mold Design (Chinese Version). Beijing: Publishing House of Electronics Industry, 2008. (In Chinese).

[3] Zhang J H, Wang S N. UG NX 5. 0 NC Programming Self-Study Handbook. Beijing: China Machine Press, 2008. (In Chinese).

[4] Yang H. UG NX5 Basic Milling Training Guide. Beijing: Tsinghua University Press, 2008. (In Chinese).

[5] Du Z M, Han H L. UG NX5 NC Programming Example Instruction (Chinese Version). Beijing: Posts & Telecom Press, 2008. (In Chinese).
