The Finite Element Analysis of a Shipyard's Lifting Eye with Load

Abstract:

As lifting points for ship block turning over and hoisting operation, the strength of the lifting eye directly affects the safety of the operation, therefore it is required for extreme high reliability. The conventional strength analysis can not exactly describe the actual stress and working conditions of the lifting eye, nonlinear contact and simplified finite element arithmetic are used for analyzing and checking the lifting eye's strength in this paper; and the stress force distribution formula, which can well reflect the true status of the pressure-bearing surface, is researched. Through the comparison of the various calculation methods, it can be found that the reasonable simplified method can approach the nonlinear contact finite element arithmetic with high precision and is characterized with higher calculation speed and more concise and practicable.

• Periodical: Advanced Materials Research (Volumes 631-632)
• Pages: 1006-1010
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.631-632.1006
• Online since: January 2013
• Authors: Shao Fen Lin, Zhao Yi Zhu
• Keywords: ANSYS, Contact Finite Element, Lifting Eye, Strength Check

References

[1] Xue Yun, Zhang Yanchang, Wang Zili, Zhai Gaojin, Liu Kun, Strength analysis on hanger using for lifing of ship block, The Fourth National Conference on Ship and Ocean Engineering, (2009).

[2] Zhou Bo, Research on Stress and Deform of Shipbuilding Dependent Processes, Dalian, Dalian University of Technology, (2008).

[3] Xu Zhishuan, Members' lifting eye Design, Port & waterway engineering, 5(2006).

[4] Ren Zhong, The practical analysis course of ansys, Beijing, Peking University Press, (2003).

[5] Xiao Wenyong, She Kai, The analysis of finite element modeling on the local of a trunnion, Ship engineering, 31(2009), 94-97.
