Research on Chamfer Software of Complex Parts

Abstract:

In order to meet the needs of enterprises for chamfering complex parts, based on the customization of commercial CAD/CAM software, chamfer programming software is developed. According to user’s machining demands for a part, a chain of edges of a part is extracted from its 3D model. With preprocessing of the chain of edges, the continuity of the chain is estimated, and the start and end point of those edges are automatic obtained. Furthermore, with human-machine dialogue, machining parameters is set by users. By definition of the primary and secondary surfaces of the chain of edges, and interpolation of the edges, the positions of cutter location point and postures of cutter are calculated. Finally the interference of tool path is checked, and tool path is simulated. The software solves the programming problem of chamfering complex parts.

• Periodical: Advanced Materials Research (Volumes 631-632)
• Pages: 1335-1341
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.631-632.1335
• Online since: January 2013
• Authors: Shi Yong, Wen Tao Liu
• Keywords: CAM, Chamfer, Edge, Planning, Tool Path

References

[1] YU Hong-ying, TANG De-wei, SAN Hong-jun. Key technologies of steam-turbine-blade's parametric design . Computer Integrated Manufacturing Systems, 2006, 12(10): 1537-1543.

[2] YU Hong-ying, LIU Ming-yu. Special numerical control machining software of blades based on UG. Journal of Harbin Institute of Technology, 2008, 40(11): 1751-1755.

[3] Song Yuwang Xi Ping. Parametric design of turbine blades based on feature modeling . Journal of Beijing University of Aeronautics and Astronautics, 2004, 30(4): 321-324.

[4] Cai Yonglin, XI Guang, Wang Shang-Jin. Machining of impeller flow tool trajectory generation . Mechanical design, 2001, (11): 37-40.

[5] Bai yu, Zhang Dinghua, Liu Weiwei. Blade part four-coordinate efficient spiral NC programming methods . Mechanical science and technology, 2003, 22(3)177-180.

[6] Ines Stassen Boehlen, Jim Fieret, Andrew S. Holmes ; Kin W. Lee. CAD/CAM software for an industrial laser manufacturing tool. Proceedings of SPIE - The International Society for Optical Engineering, 2003, 4977: 198-206.

DOI: 10.1117/12.479533

[7] Tian, Mei-Li, Xu, Yan-Shen; Xue, Zhao-Peng . CAD/CAM integration of crystallizer propeller based on unigraphics software. Journal of Tianjin University Science and Technology, 2006, 39(7): 783-787.

[8] Solomonov, K.N. Application of CAD/CAM systems for computer simulation of metal forming processes Materials Science Forum, 2012, 705: 434-439.

DOI: 10.4028/www.scientific.net/msf.704-705.434

[9] Lim, Sang-Heon1; Kim, Jae-Hyun1; Lee, Choon-Man. Development of CAD/CAM system and profile measuring device for CNC grinding machine to obtain an optimal grinding speed. Journal of Central South University of Technology, 2011, 18(2): 146-152.

DOI: 10.1007/s11771-011-0672-z
