Low-Energy Impact Damage Mechanism Analysis of FRC Laminates

Abstract:

Aimed at the lack of research about damage mechanism, a 3-D progressive impact damage analysis method was applied to analyze the low-energy impact damage process of T300/BMP-316 laminates with three different ply stacking sequences. The influences of ply parameters on the impact damage of laminates were researched. The impact damage mechanism was analyzed combined with the figure of impact stress in laminates. It is showed that the matrix cracking is caused by the inconsistent distortion of the matrix and fiber when the tensile stress that perpendicular to the fiber direction reaches a given value, and the delamination near to the impacted back face and front face are caused individually by the matrix cracking and the inconsistent bend stiffness between two laminas.

• Periodical: Advanced Materials Research (Volume 650)
• Pages: 298-303
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.650.298
• Online since: January 2013
• Authors: Ying Xu, Wei Dong Wen, Yu Huo
• Keywords: Damage Mechanism, Impact, Laminates, Numerical Simulation, Progressive Damage

References

[1] HOU JP, PETRINIC N, Ruiz C, HALLETT SR. Prediction of impact damage in composite plates[J]. Composites Science and Technology, 2000, 60: 273-281.

DOI: 10.1016/s0266-3538(99)00126-8

[2] LI CF, HU N, YIN YJ, et al. Low-velocity impact-induced damage of continuous fiber-reinforced composite laminates. Part I. An FEM numerical model[J]. Composites Part A: Applied Science and Manufacturing, 2002, 33(8): 1055-1062.

DOI: 10.1016/s1359-835x(02)00081-7

[3] XU Ying; WEN Wei-dong; CUI Hai-po. A Cumulative Damage Prediction Method of Low-Velocity Impacts on Laminated Composites[J]. Journal of Materials Science and Engineering, 2006, 24(1): 77-81.

[4] CHANG KY, LIU S, CHANG FK. Damage tolerance of laminated composites containing an open hole and subjected to tensile loadings[J]. Journal of Composite Materials, 1991, 25(3): 274-301.

DOI: 10.1177/002199839102500303

[5] MOURA M. S, MARQUES AT. Prediction of low velocity impact damage in carbon–epoxy laminates[J]. Composites Part A: Applied Science and Manufacturing, 2002, 33(3)361-368.

DOI: 10.1016/s1359-835x(01)00119-1

[6] CHOI HY, CHANG FK. A Model for Predicting Damage in Graphite/Epoxy Laminated Composites Resulting from Low-Velocity Point Impact[J]. J Compos Mater 1992; 26: 2134-69.

DOI: 10.1177/002199839202601408

[7] SUN Xian-nian，ZHENG Chang-liang. Advances on Modeling Through-the-thickness Reinforcement of Laminated Composite by z-pinning [J]. Acta Aeronouticaet Astronautica Sinica, 2006, 27(6): 1194-1202.

[8] Wen wei-dong, Xu Ying, Cui hai-po. Damage Analysis of Laminated Composites under low velocity impact loading[J]. Journal of Materials Engineering, 2007, （7）: 6-11.
