Numerical Study of Improving Aerodynamic Performance of the Cylinder Airfoil of Magnus Wind Turbine

Abstract:

To solve the problem of low lift to drag ratio of Magnus cylinder airfoil, the Computational Fluid Dynamics software Fluent was used to study the principle of a drop of the drag force of cylinder when rotating. And the principle was used to further reduce the drag of rotating cylinder. A traditional airfoil head and a triangle tail was used to study the effect of the aerodynamic performance change of the combined airfoil. A conclusion was made that with a suitable profile of the tail would reduce the drag force of the combined airfoil thus increase the lift to drag ratio of the airfoil. At last an orthogonal test was made to determine the size of the tail airfoil. The result show that the optimized airfoil reduce the drag force to 50% of the original cylinder and improve the lift to drag ratio to 50%.

• Periodical: Advanced Materials Research (Volume 650)
• Pages: 414-419
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.650.414
• Online since: January 2013
• Authors: Qi Yao, Ying Xue Yao, Liang Zhou, Jin Ming Wu, Jian Guang Li
• Keywords: Airfoil Tail, Drag Force, Lift to Drag Ratio, Magnus Effect, Rotating Cylinder

References

[1] G. Magnus. Über die abweichung der geschosse, und: Über eine abfallende erscheinung bei rotierenden körpern. Poggendorff's Annalen der Phys. und Chemie. (1853), p.1–29.

DOI: 10.1002/andp.18531640102

[2] T. F. Hanson. Magnus air turbine system. U. S. Patent, 262136. (1981).

[3] N.M. Bychkov, A.V. Dovgal, V.V. Kozlov. Magnus wind turbines as an alternative to the blade ones/Sorensen JN. Journal of Physics Conference Series, (2007).

DOI: 10.1088/1742-6596/75/1/012004

[4] Sun Ying. Research on wind turbine of vertical axis cylindrical blade. Haerbing: Haerbing Institute of Technology, 2011(in chinese).

[5] Modi, V. J., Mokhtarian, F. and Yokomizo, T., E. ect of moving surfaces on the airfoil boundary-layer control. Journal of Aircraft, Vol. 27 (1990), pp.42-50.

DOI: 10.2514/3.45894

[6] Coutanceau, M. and Menard, C., Influence of rotation on the near-wake development behind an impulsively startedcircular cylinder. Journal of Fluid Mechanics, Vol. 158 (1985), pp.399-446.

DOI: 10.1017/s0022112085002713

[7] Diaz, F., Gavalda, J., Kawall, J. G., Ke. er, J. F. and Giralt, F., Vortex shedding from a spinning cylinder. Physics of Fluids, Vol. 26 (1983), pp.3454-3460.

DOI: 10.1063/1.864127

[8] Glauert, M. B., The flow past a rapidly rotating circular cylinder. Proceedings of the Royal Society of London, Vol. 242 (1957), pp.108-115.

DOI: 10.1098/rspa.1957.0157
