A Way to Weld Sheet Metal with Double-Electrode GMAW

Abstract:

This paper designed a double-electrode GMAW(gas metal arc welding) system. This system includes main arc and bypass arc. Main arc (Base metal current: I_bm) is supplied with Constant Current power (CC mode) and bypass arc (bypass current: I_bp) is Constant Voltage power (CV mode). Main arc electrode used common carbon wire, bypass arc electrode used water cool copper. Welding experiment shows this DE-GMAW can change common metal transfer into spray transfer with lowest critical total current (I_total) 200 amps. When I_bm decreases and bypass voltage increases, this critical current will increase and it is less than 230 amps when keeping spray transfer. High speed video proved that metal transfer is changed from spray transfer to globular transfer.

• Periodical: Advanced Materials Research (Volume 651)
• Pages: 333-337
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.651.333
• Online since: January 2013
• Authors: Guo Hong Ma, Yu Ming Zhang
• Keywords: Double-Electrode, GMAW, Sheet Metal, Spray Transfer

References

[1] Zhang Y M, Jiang M, Lu W. Double electrodes improve GMAW heat input control[J]. Welding Journal, 2004, 83(11): 39–41.

[2] Li K H, Zhang Y M. Metal transfer in double-electrode gas metal arc welding[J]. Journal of Manufacturing Science and Engineering, Transactions of the ASME, 2007, 129(6): 991–999.

DOI: 10.1115/1.2769729

[3] Li K H, Chen J, Y M Zhang. Double-electrode GMAW process and control[J]. Welding Journal, 2007. 86(8): 231-237.

[4] Wu C S, Zhang M X, Li K H, Zhang, Y M. Numerical analysis of double- electrode gas metal arc welding process[J]. Computational Materials Science, 2007, 39(2): 416–423.

DOI: 10.1016/j.commatsci.2006.07.004

[5] Wu C S, Xu G X, Li K H, Zhang, Y M. Analysis of double-electrode gas metal arc welding[J]. Pine Mountain Ga, 2005, 813–817.

[6] O'Brien R L. Welding Handbook[M]. New York: American Welding Society press, (1991).

[7] Jones L A, T W Eagar, J H Lang. Investigation of drop detachment control in gas metal arc welding[C]. 3rd International Conference on Trends in Welding Research. 1992: 1009-1013.

[8] Ueguri S, K Hara, H Komura. Study of metal transfer in pulsed GMA welding[J]. Welding Journal, 1985, 64(8): 242-250.

[9] Thomsen J S. Control of pulsed gas metal arc welding[J]. International Journal of Modeling, Identification, and Control, 2006, 1(2).

[10] Lancaster J F. The Physics of Welding[M]. Oxford: International Institute of Welding, Pergamon Press, (1986).

[11] Bingul Z. Stability Consideration for the Gas Metal Arc Welding Process[D]. Nashville: Vanderbilt University, (1996).

[12] Bingul Z, Cool, G E, Barnett R J, Strauss A M, Well s. An Inverstigation of Constant Potential GMAW Instability Behavior[C]. 5th International Conference on Trends in Welding Research. 1998: 289-294.

[13] Y S Kim, T W Eager. Analyses of Metal Transfer in Gas Metal Arc Welding[J]. Welding Journal, 1993, 72: 269-278.

[14] K H LI, Zhang Y M. Consumable Double-Electrode GMAW Part1: The Process[J]. Welding Journal, 2008, 87: 11-17.

[15] K H LI, Zhang Y M. Consumable double-Electrode GMAW Part2: Monitoring, Modeling, and Control[J]. Welding Journal, 2008, 87: 44-50.
