Research on Progressive Die Design for Asymmetric U-Shaped Contactor

Abstract:

The pressing technologies and the forming difficulties of the asymmetric U-shaped contactor were analyzed. The strip layout was designed for progressive pressing from piercing to bending. The die structure was designed in three plates mode, guiding with ball cage bush and pillar mechanism. The multiple steps bending stations and sliding inclined wedge mechanism were designed to implement the critical forming function. The volume production proved that this toolset’s structure was robust at high stamping speed and the products meet the high quality criteria. A valuable universal design rule was concluded for similar product’s toolset design.

• Periodical: Advanced Materials Research (Volume 651)
• Pages: 701-705
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.651.701
• Online since: January 2013
• Authors: Zhan Feng Zhao, Li Xin Yang
• Keywords: Pressing Technologies, Progressive Die, Toolset Strip Layout, U-Shaped Contactor

References

[1] Donald A. Peterson. Progressive Dies: Principles and Practices of Design and Construction. Society of Manufacturing Engineers, (1994).

[2] David Alkire Smith. Die Design Handbook. Society of Manufacturing Engineers, (1990).

[3] J. R. Paquin, R. E. Crowley. Die Design Fundamentals. Industrial Press Inc., (1987).

[4] F Wang, L Chang. Determination of the Bending Sequence in Progressive Die Design. Journal of Engineering Manufacture, 209(1995): 67-73.
