Effect of Hydrogen Dilution on Properties of Microcrystalline Silicon Thin Films Prepared by VHF-PECVD

Abstract:

Microcrystalline silicon thin films were deposited on glass substrates by VHF-PECVD varying the ratio of hydrogen dilution from 88% to 98%. The structural characteristics, deposition rate and photosensitivity of the films were investigated. With the improvement of the hydrogen dilution ratio, crystallization rate of the films had been improved which was much more stable than amorphous silicon that the films transmit from amorphous silicon to microcrystalline silicon. However the deposition rate had been reduced with the increase of the hydrogen dilution and the highest deposition rate was 0.43nm/s. The samples showed a downward trend of photosensitivity with optical and dark conductivity both decreasing first then increasing. Thus suitable hydrogen dilution ratio should be chosen according to the different needs in preparation of microcrystalline silicon film.

• Periodical: Advanced Materials Research (Volumes 652-654)
• Pages: 1739-1742
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.652-654.1739
• Online since: January 2013
• Authors: Xia Wu, Long Gu, Ji Sen Zhang, Hui Dong Yang
• Keywords: Hydrogen Dilution, Microcrystalline Silicon Thin Films, VHF-PECVD

References

[1] Vetterl O, et al. 2000 Solar Energy Materials & Solar Cells 62 97.

[2] Shah A V, et al. 2003 Solar Energy Materials & Solar Cells 78 469.

[3] Zhang Xiaodan, et al. Study of Vertical Non- uniformity of Microcrystalline Silicon Thin Film Using Raman Spectra and AFM[J]. 2004, 33(6): 960-5.

[4] Kroll U, Meier, et al. J. Non-Cryst. Solids, 1988, 227-230: 68.

[5] Vallat Sauvain E, Hroll U, et al. Appl. Phys. 87(6): 3137.

[6] Suzuki S, Kondo M and Matsuda A. Solar Energy Materials & Solar Cells. 2002, 74: 489.

[7] Xinghan Deng, Huidong Yang , Silicon-Germanium thin Films Prepared By RF-PECVD And Its Optical Properties, The International Symposium on Photonics and Optoelectronics (sopo2010).

DOI: 10.1109/sopo.2010.5504008

[8] SUN Jian, YU Yuangao, et al. High Rate-Deposition of Microcrystalline Silicon Films and Solar Cell[J], Supporting Technology, 2006, 31(9): 697-701.

[9] Qiu Shenghua, Chen Chengzhao, et al. Effect of hydrogen dilution on crystalline properties of nano-crystalline silicon thin films in fast growth[J], Chin. Phys. Soc, 2009, 58(01): 0565-05.

[10] R. Swanepoel, Determination of the thickness and optical constants of amorphous silicon [J], J. Phys. E: Sci. Instrum., 16(1983)1214-1223.

DOI: 10.1088/0022-3735/16/12/023
