A Ku-Band Low Noise Amplifier Based on Transformer

Abstract:

The aim of this paper is to design and implement a low noise amplifier (LNA) based on transformer for a Ku-band application. The proposed CMOS LNA can have an enhanced gain because of the cascade topology, a highly flat gain response because of the RC feedback network, and a wide passband because of the source degeneration structure that effectively suppresses the Miller effect. The Ku-band LNA dissipates 22.175 mW power and achieves the S11 of -10.31 to -6.77 dB, S22 of -18.1 to -37.78 dB, flat S21 of 8.78 to 10.59 dB, and noise figure of 3.96 to 5.33 dB across the 12~18 GHz span. The measured output P1dB is approximately -2 dBm. The chip size including all testing pads is only 0.545 x 0.599 mm2.

• Periodical: Advanced Materials Research (Volumes 655-657)
• Pages: 1550-1554
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.655-657.1550
• Online since: January 2013
• Authors: Yu Lin Wang, Man Long Her, Ming Wei Hsu, Wen Ko
• Keywords: Low-Noise-Amplifier (LNA), Monolithic Microwave Integrated Circuit (MMIC), Noise Figure (NF)

References

[1] T. K. Nguyen, N. J. Oh, C. Y. Cha, Y. H. Oh, G. J. Ihm, and S. G. Lee: Image-rejection CMOS low noise amplifier design optimization techniques, IEEE Trans. Microwave Theory Tech., vol. 53, no. 2, p.538–547, Feb. (2005).

DOI: 10.1109/tmtt.2004.840744

[2] J. W. M. Rogers and C. Plett: A 5 GHz radio front-end with automatically Q-tuned notch filter and VCO, IEEE J. Solid-State Circuits, vol. 38, no. 9, p.1547–1554, Sep. (2003).

DOI: 10.1109/jssc.2003.815915

[3] Wen-Lin Chen: A Ku-band Interference-rejection CMOS Low-noise amplifier using current-reused stacked common-gate topology, IEEE vol. 17, no. 10, October (2007).

DOI: 10.1109/lmwc.2007.905631

[4] Yunseo Park, Chang-Ho Lee, Cressler, and J.D., Laskar, J.: The analysis of K-band SiGe HBT LNA for its noise, linearity, and minimum group delay variation, Microwave Theory and Techniques, IEEE Transactions on, vol. 54, no. 4, pp.1687-1697, June (2006).

DOI: 10.1109/tmtt.2006.872000

[5] Cheng-Kai Hung: Design and Implementation of the RF down converter circuit for Ku-band application, Master thesis, Department of Electronic Engineering, Feng-Chia University, Taiwan, June (2011).

[6] K. W. Yu, Y. L. Lu, D. C. Chang, V. Liang, and M. F. Chang: K-band low-noise amplifiers using 0.18 mm CMOS technology, IEEE Microw. Wireless Compon. Lett., vol. 14, no. 3, p.106–108, Mar. (2004).

DOI: 10.1109/lmwc.2004.825175

[7] Yang, H.-Y., Lin, Y.-S., Chen, C.-C.: 0.18 μm 21-27 GHz CMOS UWB LNA with 9.3 ± 1.3 dB gain and 103.9 ± 8.1 ps group delay, Electronics Letters Vol. 44, Issue 17, p.586 ~ 589, Aug. 14 (2008).

DOI: 10.1049/el:20081872
