An Automatic Product Assembly Method Based on Assembly Feature Pair

Abstract:

Assembly design and simulation plays a very important role among all stages of product design, and is the fundamental guarantee to improve the assembly performance of product. However, in current assembly design and simulation process, the detailed assembly path and the assembly position and orientation of parts are all needed to be defined through human-computer interaction. Especially when a product contains quantities of parts, there will be so many human-computer interactions to do, which can greatly increase the burden of designers. For this reason, the purpose of this paper is to study an automatic assembly method to reduce the complexity in the definition of assembly design and simulation. Firstly, we studied the intrinsic relationship between the Assembly Feature Pair (AFP) and assembly behaviors of a part, and it’s our belief that the AFP pattern of one part determines its assembly behaviors. And then we proposed an automatic product assembly method based on AFP, by which one only need to enter or specify certain parameters to achieve the assembly design and simulation of a part. Finally, a simple toolset developed based on CATIA and DELMIA using this method was introduced, and an example was given to verify the validity of this approach.

• Periodical: Advanced Materials Research (Volumes 655-657)
• Pages: 1697-1701
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.655-657.1697
• Online since: January 2013
• Authors: Yuan Liang Sun, Yuan Li, Jie Zhang, Zhi Jia Xu
• Keywords: Assembly Behavior, Assembly Design, Assembly Feature Pair, Automatic Assembly

References

[1] Hyunsoo Lee, Jonghyun Kim, Amarnath Banerjee. Collaborative intelligent CAD framework incorporating design history tracking algorithm. Computer-Aided Design, 2010, 42(12): 1125-1142.

DOI: 10.1016/j.cad.2010.08.001

[2] W.D. Li, W.F. Lu, J.Y.H. Fuh, Y.S. Wong. Collaborative computer-aided design-research and development status. Computer-Aided Design, 2005, 37(9): 931–940.

DOI: 10.1016/j.cad.2004.09.020

[3] Z.H. Jiang, J.Q. Yan. Research and development on constraint-based product family design and assembly simulation. Journal of Materials Processing Technology, 2003, 139 (1-3): 257–262.

DOI: 10.1016/s0924-0136(03)00231-0

[4] Sankar Jayaram, Uma Jayaram, etc. VADE: A Virtual Assembly Design Environment. IEEE Computer Graphics and Applications, 1999, 19(6): 44-50.

DOI: 10.1109/38.799739

[5] Terada, Y. Murata, S. Automatic assembly system for a large-scale modular structure - hardware design of module and assembler robot. Proceedings of 2004 IEEE/RSJ International Conference on Intelligent Robots and Systems. Japan: 2004, pp.2349-2355.

DOI: 10.1109/iros.2004.1389760

[6] Hiromu Onda, Hirohisa Hirukawa, Kunikatsu Takase. Assembly Motion Teaching System using Position/ Force Simulator- Extracting a Sequence of Contact State Transition. Proceedings of 1995 IEEE/RSJ International Conference on Intelligent Robots and Systems. 1995: 9-16.

DOI: 10.1109/iros.1995.525768

[7] Go J, Vu TD, Kuffner JJ. Autonomous Behaviors for Interactive Vehicle Animations. Graphical Models, 2006, 68: 90-112.

DOI: 10.1016/j.gmod.2005.04.003

[8] Marcelo Kallmann and Daniel Thalmann, Modeling Behaviors of Interactive Objects for Real-Time Virtual Environments. Journal of Visual Languages and Computing, (2002) : 177-195.

DOI: 10.1006/jvlc.2001.0229
