Analysis and Simulation for Balance of Rigid Rotors Based on ADAMS

Abstract:

Conventional models for mechanical rotors based on Automatic Dynamic Analysis of Mechanical Systems (ADAMS) are over-constraint. This paper proposes a new method for simulating the stiffness and damping of bearings using bushing and other kinematic pairs. Analysis and Simulation for balance of rigid rotors by ADAMS were performed. To reduce the imbalance inertial force, the balance weight of a take-up machine has been optimized. The results were verified by the prototype test. Our results suggest a more effective method for balance of mechanical rotors in the design stage.

• Periodical: Advanced Materials Research (Volumes 655-657)
• Pages: 412-415
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.655-657.412
• Online since: January 2013
• Authors: Zuo Shi Liu, Yi Guo Wei
• Keywords: Adam, Bearing Model, Bushing, Rotor Balance, Take-up Machine

References

[1] D.C. Han, S.H. Choi and Y.H. Lee: KSME International Journal, Vol. 12 (1998), p.397

[2] B. K. HAN, M. K. CHO and C. KIM: International Journal of Automotive Technology, Vol. 10 (2009), p.470

[3] Fengqin zhang, Hui du, and Sier Deng: Journal of Henan University of Science & Technology, Vol. 30 (2009), p.15 (In Chinese)

[4] J. K. OK, W. S. YOO and J. H. SOHN: International Journal of Automotive Technology, Vol. 9 (2008), p.184

[5] Thomas Nygards, Viktor Berbyuk: Multibody Syst Dyn, Vol. 27 (2012), p.222

[6] Sier Deng, Qunyi Jia: Design Principle of the Rolling Bearing (China Zhijian Publishing House, Beijing, 2008, In Chinese)

[7] Hao Wu, Jianwe Wang. Bearing, Vol.2 (2009), p.9 (In Chinese)

[8] Shengli An, Liming Yang: Techniques for Rotor Balance in Situ (National Defense Industry Press, Beijing, 2007, In Chinese)
