The Virtual Prototype Modeling Research of a Wind Tunnel Test Platform with Member Flexibility

Abstract:

The rigid-flexible hybrid modeling of the wind tunnel test platform is established by means of ANSYS and ADAMS for more accurate analysis of the motion performance of the test platform in this paper. We get the kinematical characteristic curve based on the three working conditions of the pitching motion, yawing motion, rolling motion of the test platform. According to the characteristic curve indirectly reflects the rationality of the design configuration. So as to provide fundamental basis for the precision dynamics simulation analysis and make the real physical prototype are offered.

• Periodical: Advanced Materials Research (Volumes 655-657)
• Pages: 425-429
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.655-657.425
• Online since: January 2013
• Authors: Lan Lei Zhao, Wen Jia Chen, Li Jun Shi, Lu Yang Li, Yan Zhong He
• Keywords: Characteristic Curves, Physical Prototype, Rigid-Flexible Hybrid, Wind Tunnel Test Platform

References

[1] X.P. Zhang, James K. Mills and William L. Cleghorn: Investigation of axial forces on dynamic properties of a flexible 3-PRR planar parallel manipulator moving with high speed,Robot.,Vol. 28, No. 4 (2009), pp.607-619.

DOI: 10.1017/s0263574709990282

[2] J. F. Hu, and X. M. Zhang: Elastodynamic analysis of a novel 2-DOF high-speed parallel manipulator, Journal of South China University of Technology (Natural Science Edition), vol. 37, No. 11 (2009),pp.123-128.

[3] Z.C. Zhu, Zh.k. Li, CH.SH. Liu, Y. Q. Yu: Kinematics and Dynamics of 3-RRC Flexible Parallel Manipulator, ICEE (2010), pp.1-4.

[4] J. F. Hu, and X. M. Zhang, "Optimal design of a novel 2-DoF flexible parallel manipulator," Robot., vol. 32, No. 4 (2010), pp.123-128.

DOI: 10.3724/sp.j.1218.2010.00459

[5] M. Madani, M. Moallem: Hybrid position/force control of a flexible parallel manipulator,J. FRANKLIN. I., Vol. 348, No. 1 (2011), pp.999-1012.

DOI: 10.1016/j.jfranklin.2011.03.005

[6] M. Rein, G. Höhler, A. Schütte, A. Bergmann, T. Löer: Ground-based simulation of complex maneuvers of a delta -wing aircraft, AIAA Journal of Aircraft , Vol. 45, No.1 (2008),pp.286-291.

DOI: 10.2514/1.30033

[7] Q. L. Hu, G. F. Ma: Variable structure control and active vibration suppression of flexible spacecraft during attitude maneuver, AEROSP. SCI. TECHNOL., Vol. 9, No. 4 (2005), pp.307-317.

DOI: 10.1016/j.ast.2005.02.001

[8] J.f. Hu: Vibration Suppression of a High-Speed Flexible Parallel Manipulator Based on Its Inverse Dynamics, ISDEA (2012), pp.744-747.

DOI: 10.1109/isdea.2012.605
