CFD Simulation on Flow Distribution in Plate-Fin Heat Exchangers

Abstract:

The influences of the conventional header configuration used in industry at present on the fluid flow distribution in plate-fin heat exchanger were numerically investigated. The numerical results showed that the fluid flow maldistribution is very serious in the heat exchanger. The header configuration with perforated plate was brought forward for the first time. The computational results indicated that the improved header configuration can effectively improve the performance of fluid flow distribution in the heat exchanger. The fluid flow distribution for the header configuration with curving perforated plate is more uniform than for the header configuration with plane perforated plate. The absolute degree of fluid flow nonuniformity in plate-fin heat exchanger has reduced from 3.47 to 0.32 by changing the header configuration. The numerical results are compared with the experimental results. They are basically consistent which indicates that the mathematical model and the calculating method are reliable.

• Periodical: Advanced Materials Research (Volumes 655-657)
• Pages: 445-448
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.655-657.445
• Online since: January 2013
• Authors: Zhe Zhang, Jin Jin Tian, Yong Gang Guo
• Keywords: Flow Distribution, Header Configuration, Plate-Fin Heat Exchanger

References

[1] A. C. Mueller: Effects of some types of maldistribution on the performance of heat exchangers. Heat Transfer Engineering, Vol. 8(2) (1987), pp.75-86.

DOI: 10.1080/01457638708962795

[2] M. W. Kays, A. L. London, Compact heat exchangers, (McGraw-Hill, New York 1964).

[3] C. H. Ranganayakulu, K. N. Seetharamu: The combined effects of longitudinal heat conduction flow nonuniformity and temperature nonuniformity in crossflow plate-fin heat exchanger. International Communications in Heat Mass Transfer, Vol. 26 (5) (1999).

DOI: 10.1016/s0735-1933(99)00053-6

[4] C. H. Ranganayakulu, K. N. Seetharamu: The combined effects of wall longitudinal heat conduction, inlet fluid flow nonuniformity and temperature nonuniformity in compact tube-fin heat exchangers: a finite element method, Int. J. Heat Mass Transfer, Vol. 42(2) (1999).

DOI: 10.1016/s0017-9310(98)00156-2

[5] A. J. Jiao, Y. Z. Li, R. Zhang, A Study of the configuration and performance of distributor in plate-fin heat exchanger, in: Proceedings of the 18th International Cryogenic Engineering Conference (ICEC18), 299—302, Mumbai, India(2000).

[6] Y. Z. Li, A. J. Jiao, C. Z. Chen, Development of compact heat exchangers and their applications in refrigeration and cryogenics, in: Proceedings of Beijing International Conference on Cryogenics, 211—214, Beijing, China(2000).

[7] Kitto J. B., Robertson J. M.: Effects of maldistribution of flow on heat transfer equipment performance. Heat Transfer Engineering, Vol. 10(1) (1989), pp.18-25.

DOI: 10.1080/01457638908939688

[8] J. P. Chiou: Thermal performance deterioration in crossflow heat exchanger due to flow nonuniformity. Journal of Heat Transfer, Vol. 100 (1) (1978), pp.580-587.

DOI: 10.1115/1.3450860
