Structural Dynamic Analysis and Optimization of High-Speed Precision Machining Center Column

Abstract:

The theory of structural dynamic analysis is put forward firstly. Then the dynamic performance of HMC80 high-speed precision machining center column is analyzed by means of finite element method. The dynamic performance of the column is analyzed using structural dynamic optimization theory and variation analysis with the thickness of wall plate and the inner rib plates as the parameters thirdly. Based on the analysis results, the structure optimization scheme of the column is obtained. The structure optimization scheme is analyzed and the analysis results show that the dynamic performance of the column optimization scheme is improved obviously.
