Experiment on Flexural Behavior of Bridge Structure Reinforced with a Novel FRP Material Based on Scale Model

Abstract:

: Taken a reinforced concrete beam bridge which has 20 m main span as an example，based on similarity theory，9 scale model beams of T-beam were designed in accordance with CL= 1/4. The test was divided into three groups: test I: contrast beams without reinforcement，test II: reinforced beams without considering the secondary load，and test III: reinforced beams considering the secondary load. The ultimate load，crack propagation，strain of basalt fiber reinforced polymer (a novel FRP material) sheet and the ultimate failure mode of the beams reinforced by BFRP sheet in the cases of test II and test III discussed. By comparing the results of three tests，it shows that (1) the average deflections of test II and test III decreased by 36.7% and28.9% respectively than that of test I; (2) the final average strains of BFRP sheet in test II and test III are 15118 με and 10921 με which are 84. 4% and 61. 0% of the ultimate tensile strain of BFRP sheet respectively，indicating the stiffness of beams is increased after reinforced by BFRP sheet and the reinforcement effect of test II is better than that of test III; (3) all the ultimate failure mode of reinforced beams are brittle failure.

• Periodical: Advanced Materials Research (Volume 661)
• Pages: 145-149
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.661.145
• Online since: February 2013
• Authors: Yi Lai, Han Bin Yi, Xiang Lin Jiang
• Keywords: BFRP Sheet, RC T-Beam, Reinforcement, Scale Model Test

References

[1] OUYANG Yu, WANG Peng, LI Xiang. Experimental Study on Flexural RC Beams Strengthened with BFRP Sheets [J]. Journal of Building Structure, 2008, 38( 11) : 74-78.

[2] MEDVEDYEV O O, TSYBULYA Y L. The Outlook for the Use of Basalt Continuous Fibers for Composite Reinforcement [C]/International SAMPE Technical Conference. Long Beach, CA: International SAMPE Technical Conference, 2004: 275 -279.

[3] OUYANG Yu, QIAN Zaizi. The Analysis of Bonding Shear Stress of RC Beams Strengthened with Plate [J]. Engineering Mechanics, 2000, 17(6) : 31-34.

[4] WU Gang, JIANG Jianbiao. Experimental Study on the Performance of RC Beams Strengthened with Basalt Fiber Sheet [J]. Special Structures, 2007, 24 (6: )43 -47.

[5] QIN Shihong, TIAN Chuxing. Research on Mechanical Behaviors of Slab-column Integral Structures Strengthened with BFRP [J]. Engineering Mechanics, 2009, 26(6): 133-140.

[6] ZHANG Guanyong. Test of Bridge Structure [M]. Beijing: China Communications Press, (2002).

[7] JTG D62-2004, Code for Design of Highway Reinforced Concrete and Prestressed Concrete Bridges and Culverts[S].
