Finite Element Analysis on the Crack Width and Deflection of a Local Corroded Reinforced Concrete Beam

Abstract:

In this paper, the crack width and deflection of a local corroded reinforced concrete beam is investigated. The influence of the rebar corrosion on a concrete beam is analyzed first. Based on the constitutive relationship of the corroded reinforced concrete, the corroded reinforced concrete is regarded as a bond-slip composite beam which is comprised of corroded rebar and concrete. By using the large-scale finite element software ANSYS, a separate reinforced concrete beam model is developed after selecting the reasonable element. By using the proposed model, the positions of the cracks are determined. Moreover, the cracks width and the deflection of the beam at the corroded segment are calculated through using formula and extracting the results data from ANSYS. At last, the results by the standard design of concrete structures (GB50010-2010) and EN1992-1-1:2004[1] are compared through the list, which show the crack width and deflection of the local corroded reinforced concrete beams calculated by ANSYS is feasible.

• Periodical: Advanced Materials Research (Volume 663)
• Pages: 219-224
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.663.219
• Online since: February 2013
• Authors: Qi Yin Shi, Chun Zhao, Chun Wang, Qing Li
• Keywords: Bond, Crack Width, Localized Corrosion, Slip, Smeared Crack

References

[1] Mao-mao Du, Calculation of crack width of Chinese, American and European concrete codes, Journal of Zhengzhou university of light industry(Natural Science). 2012, Vol. 27 No. 2.

[2] Wei-jun Zhang, Finite element analysis of mechanical behavior for reinforced concrete structure considering crack propagation, Master degree thesis of Tianjin University. (2011).

[3] Wei-liang Jin, Jin XIA, Ao-yu Jiang, et al, Flexural capacity of corrosion－{TTP}-243 damaged RC beam [J]. China Civil Engineering Journal, 2009, 42 (11): 64－{TTP}-243 70.

[4] Ning Xu, Jian-chang Zhao, Quan-hong Chen, Nonlinear finite element analysis of longitudinally and non-uniformly corroded beams, Journal of Lanzhou University of Technology, 2008, Vol. 34 No. 3.

[5] Shi-feng Hou, The research of crack distribution and width of reinforced concrete structure based on ANSYS, Master degree thesis of Central South University, (2009).

[6] Jie Bai, Zhi-jun Wang, Qiao-ling Gao, Zhi-liang Li, Zong-ming Huang, Average Constitutional Relationship of Unanchored Zone of RC Structure with Considering Bond and Slip, Journal of Civil, Architectural & Environmental Engineering, 2009, Vol. 31 No. 2.
