Effect of Pantograph and Bogie on Interior Noise of High-Speed Train in Tunnel

Abstract:

For clarifying the noise in tunnel affected by pantograph and bogie, which are the most important noise sources, the noises near pantograph and bogie in a high-speed train were tested by multi-channel noise measurement and analysis system in tunnel, and compared with those measured outside the High-speed train and on an open field. The results show that the interior vehicle noise is spatially non-homogeneous in the whole carriage, the larger sound pressure level (SPL) near pantograph are next to ceiling, and near bogie next to floor. The noise spectra show a broad band feature, and dominated by the frequency contents among 100Hz-2kHz, so the countermeasures against noise should be within these range.

• Periodical: Advanced Materials Research (Volume 664)
• Pages: 191-196
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.664.191
• Online since: February 2013
• Authors: You Gang Xiao, Yu Shi
• Keywords: Bogie, High Speed Train (HST), Noise, Pantograph, Tunnel

References

[1] Xiaofeng Zhang, Yougang Xiao, and Helian Deng, Noise source localization investigation in high speed train based on microphone array, Applied Mechanics and Materials. 103 (2012) 285-291.

DOI: 10.4028/www.scientific.net/amm.103.285

[2] Iwamoto K, Higashi A, Some consideration toward reducing aerodynamic noise on pantograph, Japanese Railway Engineering. 122 (1993) 1-4.

[3] Sueki T, Ikeda M, Takaishi T, Aerodynamic noise reduction using porous materials and their application to high-speed pantographs, Quarterly Report of Railway Technical Research Institute. 50(2009) 26-31.

DOI: 10.2219/rtriqr.50.26

[4] Iwamoto K, Higashi A, Some consideration toward reducing aerodynamic noise on pantograph, Japanese Railway Engineering. 122 (1993) 1-4.

[5] Fremion N, Vincent N, and Jacob M. Aerodynamic noise radiated by the intercoach spacing and the bogie of a high-speed train. Journal of Sound and Vibration, 231(2000) 577-593.

DOI: 10.1006/jsvi.1999.2546

[6] Lee J, Cho W. Prediction of low-speed aerodynamic load and aeroacoustic noise around simplified panhead section model. Proceedings of the Institution of Mechanical Engineers, Part F: Journal of Rail and Rapid Transit, 222(2008) 423-431.

DOI: 10.1243/09544097jrrt152

[7] Ikeda M, Suzuki M, and Yoshida K. Study on optimization of panhead shape possessing low noise and stable aerodynamic characteristics. Quarterly Report of Railway Technical Research Institute, 47(2006): 72-77.

DOI: 10.2219/rtriqr.47.72

[8] Sunghoon Choi, Chan-Woo Lee, Jae-Chul Kim, and Joon-Ho Cho. Interior Noise of a Korean High-Speed Train in Tunnels. Proceedings of acoustics, 2004: 415-419.
