Transformer Mineral Oil Mixtures Characterization by Isothermal Charging Currents

Abstract:

This work aims at the characterization of power transformer oil mixtures by using dc charging currents measurements for long field application times. The principle of this approach is inspired from the technique of measurements carried out on solid dielectrics used in high voltage insulation. It will be applied to characterize mixtures between two compatible oils of different provenances and ages. The obtained results are conclusive and reinforce those obtained by classical physicochemical methods of characterization. For the purpose, we intent to link between the space charge behavior in the insulation and its several characteristics. Moreover, in addition to the fact that the obtained results are in good agreement with the physicochemical characteristics, the charging currents reported at room temperature enabled us to determine the mixture resistivity and charge carriers' mobility.

• Periodical: Advanced Materials Research (Volume 664)
• Pages: 632-637
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.664.632
• Online since: February 2013
• Authors: Tahar Toudja, Hocine Moulai, Azzeddine Nacer, Abdeslem Beldjillali, Nadia Saidi, Mohamed Saidi
• Keywords: Characterization, Conduction Currents, Mineral Oils, Mixtures, Transformer Insulation

References

[1] I. Fofana, H. Borsi and E. Gockenbach, 'Fundamental investigations on some transformer liquids under various outdoor conditions', IEEE Transactions on Dielectrics and Electrical Insulation, Volume: 8 No. 6, pp.1040-1047, (2001).

DOI: 10.1109/94.971463

[2] R. Bartnikas, 'Some general remarks on the dielectric loss mechanisms in mineral oils', IEEE Transactions on Dielectrics and Electrical Insulation, Vol. 16 No. 6, p.1506 – 1510, (2009).

DOI: 10.1109/tdei.2009.5361568

[3] J.K. Nelson, M.A. Brubaker and J.A. Palmer, 'The formulation of models for the description of the streaming electrification in transformer structures', IEEE Transactions on Dielectrics and Electrical Insulation, Vol. 10 No. 6, pp.920-932, (2003).

DOI: 10.1109/tdei.2003.1255768

[4] Walter S. Zaengl, ' Dielectric Spectroscopy in Time and Frequency Domain for HV Power Equipment, Part I: Theoretical Considerations', IEEE Electrical Insulation Magazine, Vol. 19, No. 5, pp.5-19, (2003).

DOI: 10.1109/mei.2003.1238713

[5] Walter S. Zaengl, ' Applications of Dielectric Spectroscopy in Time and Frequency Domain for HV Power Equipment', Vol. 19, No. 6, pp.9-22, (2003).

DOI: 10.1109/mei.2003.1266348

[6] CIGRÉ Task Force 15. 01. 09: S.M. Gubanski, P. Boss, G. Csépes, V. Der Houhanessian, J. Filippini, P. Guuinic, U. Gäfvert, V. Karius, J. Lapworth, G. Urbani, P. Werelius, W. Zaengl, 'Dielectric Response Methods for Diagnostics of Power Transformers', IEEE Electrical Insulation Magazine, Vol. 19, No. 3, pp.12-18, (2003).

DOI: 10.1109/mei.2003.1203017

[7] T.K. Saha, 'Review of modern diagnostic techniques for assessing insulation condition in aged transformers', IEEE Transactions on Dielectrics and Electrical Insulation, Vol. 10 No. 5, pp.903-917, (2003).

DOI: 10.1109/tdei.2003.1237337

[8] R. Coelho and B. Aladenize. Dielectric properties of the insulator materials, Hermes Edition, Paris, (1993).

[9] R. Tobazeon, Study of the interface phenomena in contact of an insulating liquid and solid, Doctorat thesis of science, Grenoble, France, (1973).

[10] P. Atten and R. Moreau, Electro hydrodynamic Stability of insulator liquids submitted to an unipolar injection, Mec. Jour., Vol. 11, pp.471-520, (1972).

[11] A. Many and G. Rakavy, Phys. Rev., Vol. 126, p.1980, (1962).

[12] H. Moulai, I. Khelfane, A. Yahiat, T. Toudja, A. Nacer, M. M. Zemirli and F. Doussas, Physico-Chemical Properties of Power Transformer Oil Mixtures, 15th IEEE Mediterranean Electrotechnical Conference, MELECON 2010, 2010, Valletta, Malta.

DOI: 10.1109/melcon.2010.5476358
