Electromagnetic Performance Analysis of Claw-Pole Alternator with Changing Permeance

Abstract:

A changing air gap permeance model of the alternator and its influence were discussed in this paper. When the alternator was under high-speed operation, taking it into consideration that the claws getting deformation for rotating centrifugal force and electromagnetic exciting force, the alternator’s changing air gap permeance model was established. And the alternator’s Maxwell3D calculation model was built. The field magnetic distribution under the rated speed was obtained as well, also before the claws’ deformation was obtained. The harmonics of the air-gap flux were analyzed and compared. The changing air gap permeance model was proved to be reasonable. It would lead to air-gap magnetic field distortion of the generator, which affected the generator’s electromagnetic properties. Instruction was provided for more precise of air gap magnetic field analysis or vibration noise analysis of alternator.

• Periodical: Advanced Materials Research (Volume 668)
• Pages: 510-513
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.668.510
• Online since: March 2013
• Authors: Xiao Hua Bao, Mou Zhi Liu
• Keywords: Air-Gap Magnetic Field, Alternator, Changing Permeance, Harmonic Analysis

References

[1] H. Bai, S. Pekarek, J. Tichenor, W. Eversmann, D. Buening, G. Holbrok, M. Hull, R. Krefta, and S. Shields, Analytical Derivation of a Coupled–Circuit Model of a Claw–Pole Alternator With Concentrated Stator Windings, IEEE Transactions on Energy Conversion, 2002, 17(1)：32-38.

DOI: 10.1109/60.986434

[2] Sang-Ho Lee, Soon-O Kwon, Jeong-Jong Lee, Jung-Pyo Hong. Characteristic Analysis of Claw-Pole Machine Using Improved Equivalent Magnetic Circuit, IEEE Transactions on Magnetics, 2009, 45(10): 4570-4573.

DOI: 10.1109/tmag.2009.2023429

[3] Zarko,D. Ban,D. Lipo T.A. Analytical Calculation of Magnetic Field Distribution in the Slotted Air Gap of a Surface Permanent-Magnet Motor Using Complex Relative Air-Gap Permeance, IEEE Transactions on Magnetics, 2006, 42(7): 1828-1837.

DOI: 10.1109/tmag.2006.874594

[4] Hafner,M. Franck,D. Hameyer,K. Static Electromagnetic Field Computation by Conformal Mapping in Permanent Magnet Synchronous Machines, IEEE Transactions on Magnetics, 2010, 46(8): 3105-3108.

DOI: 10.1109/tmag.2010.2043930

[5] Ceban, A. Pusca, R. Romary, R. Study of Rotor Faults in Induction Motors Using External Magnetic Field Analysis, IEEE Transactions on Industrial Electronics, 2012, 59(5): 2082-(2093).

DOI: 10.1109/tie.2011.2163285

[6] Shigui Zhou, Haitao Yu, Minqiang Hu, Chongxue Jiang, Lei Huang. Nonlinear Equivalent Magnetic Circuit Analysis for Linear Flux-Switching Permanent Magnet Machines, IEEE Transactions on Magnetics, 2012, 48(2): 883-886.

DOI: 10.1109/tmag.2011.2173467
