Model Identification and Dynamic Performance Analysis of Fast Tool Servo System with High Frequency Response

Abstract:

Fast tool servo system could achieve precise and efficient processing of fine micro-structure for its fast and accuracy response to input control signal, which will directly affect the processing quality of the workpiece surface. Different structural forms of fast tool servo system have been designed and presented in China and overseas, with which generally low the stiffness and natural frequency, only can be used for the rule and the characteristic scale of the larger surface processing. A fast tool servo system whose thrust was up to 12500N, stiffness was 280N/μm, the natural frequency was more than 3kHz , was developed in this paper, as well as the analytical expression of time domain and frequency domain output，which were presented by the modeling analysis; The unknown parameters of the system model were identified by frequency response test. The theoretical and experimental results indicated that the system has good dynamic performance to meet the fine micro-structure of highly efficient, high-precision processing needs.

• Periodical: Advanced Materials Research (Volume 669)
• Pages: 273-278
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.669.273
• Online since: March 2013
• Authors: Ke Jie Wen, Gui Lin Wang, Fan Yang
• Keywords: Dynamic Performance, Fast Tool Servo System, High Frequency Response, Model Identification

References

[1] Guilin Wang, Yifan Dai, Ziwen Zheng, et al. Machining characteristics of complex surfaces using fast tool servo system. Machining Science and Technology, 2011, 15(3): 324-337.

DOI: 10.1080/10910344.2011.600199

[2] E. Brinksmeier, O. Riemer, et al. Submicron functional surfaces generated by diamond machining. CIRP Annals - Manufacturing Technology, 2010(59): 535-538.

DOI: 10.1016/j.cirp.2010.03.037

[3] Hiroyuki Mochizuki, Wataru Watanabe, et al. Fabrication of diffractive optical elements inside polymers by femtosecond laser irradiation. Thin Solid Films, 2009(518): 714-718.

DOI: 10.1016/j.tsf.2009.07.076

[4] Claas Falldorf, Colin Dankwart, et al. Holographic projection based on diamond-turned diffractive optical elements. Applied Optics, 2009, 48(30): 5782-5785.

DOI: 10.1364/ao.48.005782

[5] D.P. Yu, Y.S. Wong, G.S. Hong. Ultraprecision machining of micro-structured functional surfaces on brittle materials. Journal of micromechanics and microengineering, 2011(21): 1-11.

DOI: 10.1088/0960-1317/21/9/095011

[6] Colin Dankwart，Claas Falldorf，Ralf Gläbe, et al. Design of diamond-turned holograms incorporating properties of the fabrication process. Optical Society of America, 2010, 49(20): 3949-3955.

DOI: 10.1364/ao.49.003949

[7] C.F. Cheung, K. Hu, X.Q. Jiang, et al. Characterization of surface defects in fast tool servo machining of microlens array using a pattern recognition and analysis method. Measurement, 2010(43): 1240-1249.

DOI: 10.1016/j.measurement.2010.06.003
