Study on Giant Magnetostrictive Material with Design and Simulation of Displacement Magnifying Mechanism

Abstract:

In order to make full use of advantages of giant magnetostrictive material and to improve output characteristics of giant magnetostrictive actuator, displacement magnifying mechanism is designed based on flexible hinges. The design parameter of the flexible hinges and strength of material of flexible hinges are calculated. Based on the analysis and comparison, the statics and dynamics analysis was carried on by analytic method and ANSYS12.1 software,the input stiffness, magnifying multiple and the relationship between output displacement and load are calculated,and the stress analysis shows that the maximum stress of magnifying mechanism is less than the maximum allowable stress of materials. The resonance frequency,vibration modes and harmonic response of the mechanism were resulted by Finite element method, and the dynamics parameters of system are get.

• Periodical: Advanced Materials Research (Volume 675)
• Pages: 219-226
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.675.219
• Online since: March 2013
• Authors: Fan Zeng, Jing Jun Lou, Shi Jian Zhu
• Keywords: Displacement Magnifying Mechanism, Finite Element Analysis (FEA), Flexible Hinges, Giant Magnetostrictive Actuator

References

[1] LUO Yi-jing, LI Li, YU Ming-lang. The Design of Parallel Micromanipulator Based on COSMOS. JOURNAL OF DONGHUA UNIVERSITY(NATURAL SCIENCE). 2008, 34(3) : 307-310 in Chinese.

[2] Yu Zhi-yuan, Yao Xiao-xian, Song Xiao-dong. Design of micro-displacement amplifier based on flexure hinges. Chinese Journal of Scientific Instrument. 2009, 30(9)：1818-1822 in Chinese.

[3] ZHANG Lei, LIU Ying. Design of Micro-displacement Mechanism Based on Flexure Hinges. MACH INE TOOL & HYDRAULICS. 2010, 38(5) ：87-89 in Chinese.

[4] WANG Si-min, YUN Xia, CHEN Jun-zheng. Design and Analysis on Micro Displacement Magnifying Mechanism with Flexible Hinges. Hydraulics Pneumatics & Seals. 2011(1)：17-19 in Chinese.

[5] ZHOU Zhi-ping, 　WANG Long-tai, 　MA Zhi-xin. Design and Analysis on Two-stage Symmetric Displacement Magnifying Mechanism With Flexible Hinges. Machine Design and Research. 2006, 22(5)：62-64 in Chinese.

[6] YU Jing-jun, BI Shu-sheng, ZONG Guang-hua. Study on the Design of Fully Compliant Motion Amplification Mechanisms in Actuation Systems for Micromanipulators. ACTA AERONAUTICA ET ASTRONAUTICA SINICA. 2004, 25(1)：74-78 in Chinese.

[7] MA Hao-quan, HU De-jin, ZHANG Kai. Application of Flexure-hinge Micro-motion Amplifier in Piston Turning. PIEZO ELECTRICS &ACOUSTO OPTICS. 2004, 26(6)：514-516 in Chinese.

[8] SUN Bao-yu. Experimental Research on Dynamic Characteristic of Flexible Micro2displacement Mechanism Based on Piezoelectric Actuator. MICROFABRICATION TECHNOLOGY. 2008(2)：33-35 in Chinese.

[9] WANG Hong-feng, CHEN Dao-jiong, LIU Wei. Design and Simulation of a 3-DOF M icro-positioning Worktable. PIEZOELECTRICS & ACOUSTOOPTICS. 2010, 32(5)：803-806 in Chinese.

[10] WANG Xin-hua, XIAO Feng, WANG Si-min, MA Yong-chao. Finite element analysis for output displacement of diphase oppositing giant magnetostrictive actuator. Machinery Design & Manufacture. 2009(2)：61-63 in Chinese.

[11] WU Meng, ZHU Xi-lin, ZHENG Hui. New type of actuate-motion mechanism with giant magnetostrictive and piezoelectric drive. JOURNAL OF HARBIN INSTITUTE OF TECHNOLOGY. 2009, 41（1）：149-151 in Chinese.

[12] Li Fu. RESEARCH ON GIANT MAGNETOSTRIVE ACTUATOR IN THE APPLICATION OF ELECTRONIC CONTROL VALVE. Thesis of Hebei University of Technology. 2007, 12：16-17 in Chinese.
