Research on Electrical Power System with Analysis of Fault Operation State Magnetic Field about DFIG in Wind Power

Abstract:

Doubly-fed Induction Generator (DFIG) is an important equipment in electrical power system. Operation state of DFIG is complex: it works at subsynchronism, synchronization and hypersynchrony state. Electromagnetic field is various. There is winding on stator and rotor, it’s more possible for fault to happen. Text discuss structure of DFIG, finite element method (FEM) model including stator rotor and air-gap is created, typical magnetic field is calculated including normal operation state, turn-to-turn and single-phase short-circuit happened, result is analysed, distribution discipline of multiple magnetic field is obtained. It provide the evidence to early failure prediction, basic data to develop and design high-capacity generator, optimize structure and magnetic field analysis of DFIG.

• Periodical: Advanced Materials Research (Volume 676)
• Pages: 181-185
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.676.181
• Online since: March 2013
• Authors: Shan He, Wei Qing Wang, Hai Yun Wang, Xin Yan Zhang, Jing Cheng, Jie Chen
• Keywords: DFIG in Wind Power, Electrical Power System, Fault Operation State, Magnetic Field

References

[1] Pak, Lok-Fu. Real-time simulation of a wind energy system based on the doubly-fed induction generator. IEEE Transactions on Power Systems, Vol.24(2009),pp.1301-1309.

DOI: 10.1109/tpwrs.2009.2021200

[2] ISLAM MJ, ARKKIO A. Effects of pulse-width-modulated supply voltage on eddy currents in the form-wound stator winding of a cage induction motor. IET Electr Power Appl, Vol. 3(2009), pp.50-58.

DOI: 10.1049/iet-epa:20080060

[3] Duan Xiaotian, Zhang Xinyan, Zhang Jun. Finite Element Based Electromagnetic Field Simulation and Analysis of Doubly Fed Induction Generator. Power System Technology,Vol.36(2012),pp.231-236.

[4] Qian Yayun, Ma Hongzhong. A Survey of Fault Diagnosis Method for Doubly-fed Induction Motor. Large Electric Machine and Hydraulic Turbine, Vol. 5(2011), pp.5-8.

[5] Zhao Zheng, Liu Huijuan, Zhang Qian. Analysis of Electromagnetic and Temperature Field of a Novel Brushless Doubly Fed Machine with Radial Laminated Reluctance Rotor. Micromotors, Vol. 44(2011), pp.13-16.

[6] Hou Xinguo, Wu Zhengguo, Xia Li, et al. Stator winding fault diagnosis method of induction motor based on coherence analysis. Proceedings of the CSEE , Vol. 25(2005), pp.83-86.

[7] Li Junqing, MA Li, Wang Deyan. Influence of stator turn-to-turn short-circuit on Magnetic field of DFIG, IEEE Transactions on Energy Conversion, Vol. 24(2009), pp.557-564.

[8] Mei Baishan, Liu Haihua, Zhang Jinping. FEM Analysis of Electromagnetic Field of Mega Watt Level DFIG.Micromotors,Vol.43(2010),pp.26-29.

[9] Zhang Chao, Xia Li. Reviews on fault diagnosis for AC brushless generators. Journal of Hunan University of Technology, Vol.21(2007),pp.103-106.

[10] Gritli Y, Stefani A, Filippetti F. Stator Fault Analysis Based on Wavelet Technique for Wind Turbine Equipped with DFIG[C]. International Conference on Clean Electrical Power, Tunisia, 2009:485-491.

DOI: 10.1109/iccep.2009.5212008
