Influence of the Arc Suppression Coil with Parallel Resistance on Single-Phase Arc Grounding Overvoltage

Abstract:

Neutral point grounding method with an arc suppression coil and a parallel resistance is a method that can inhibit arc overvoltage effectively. Through the simulation of arc suppression coil with parallel resistance in the situation of different resistance value, we can obtain if the parallel resistance is too big, it will produce overvoltage in the later of voltage recovery; if the parallel resistance is too small, it is easy to produce larger grounding residual flow, going against quenching of arc; Whether over compensation or owe compensation, oversized out-of-resonance degree will cause the fault phase voltage recovery oscillation overvoltage, small out-of-resonance degree is beneficial to the fault phase voltage rise slowly.

You might also be interested in these eBooks

Advanced Research on Material Engineering and Electrical Engineering

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 676)

Pages:

284-288

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.676.284

Citation:

Cite this paper

Online since:

March 2013

Authors:

Han Xue, Ji Jiang Song, Yu Chong Cui

Keywords:

Arc-Suppression Coil, Damping Rate, Out-of-Resonance Degree, Overvoltage, Parallel Resistance

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] ChunYan Ma, ZhaoQing Yuan, in: Study on neutral grounding models of the power distribution system, Techniques of Automation and Application Publishing( 2006)

Google Scholar

[2] XuSheng Jiao, in: Principles of the line detection in resonant grounding, Power Equipment Publishing (2002).

Google Scholar

[3] HongChun Shu, in: Fault line selection of distribution power system, China Machine Publications (2008)

Google Scholar

[4] HongBin Ji, in: Optimize of Earth Fault Protection by Parallel resistance on resonance earth system, High Voltage Engineering Publishing(2006)

Google Scholar

[5] XianChen Wei, in: Grid overvoltage tutorial, China Electric Power Publications (1988)

Google Scholar

[6] DongMing Qiu, in: Simulation and analysis of overvoltage caused by arc grounding in 10kV distribution power grid, Chongqing University Publishing (2003)

Google Scholar
