Study on Electromechanical Coupling Vibration of Simulation Technology Based on the Drive System

Abstract:

Study the mechanical and electrical system,according to the mechanical system of the coupling mechanics principle, the AC drive system is simplified as many degrees of freedom "spring - mass - damper" system,the quality of construction of three two-axis system,established the two shafts electromechanical coupling vibration mathematical model; Using the electromechanical coupling vibration simulation model, the parameters of the current regulator, damping, harmonic disturbances, gap and load disturbance of electromechanical coupling factors such as vibrations caused by dynamic process.Improve the dynamic performance of the system is significant, have the great value for the parameters of the system design and fault diagnosis on this study.

• Periodical: Advanced Materials Research (Volume 676)
• Pages: 289-292
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.676.289
• Online since: March 2013
• Authors: Hong Ying Wang
• Keywords: Characteristic Analysis, Coupling, Model, Signal, Vibration

References

[1] Cai haixiang, Xiong wanli, Lvlang.Modeling on the Non-stationary Starting Process of SPWM Frequency Control and Mechanic Rotor System.Machinery and electronics .2006 (5) P54-56.

[2] Lin lihong,Chen xiaoan,Zhou chaoqun, Modeling and Simulation analysis on Electromechanical Coupling of Precision Transmission System. Chongqing University (Natural Science) .2007.30 (11) P14-18.

[3] Pang haiping,,Liu chengju,Jiang zhuyan,Sliding mode fuzzy control for permanent magnetic synchronous motor Ac servo systems. Machines and Control .2006.10 (6) P576-579.

[4] An quntao,Study on the position control and related technology research of Permanent magnet AC servo systems. Harbin Institute of Technology in Heilongjiang .2006.

[5] Chen xianfeng,Study on analysis and design and its application of PMSM position, Jiangsu: Nanjing University.2005.

[6] Lin lihong,Electromechanical Coupling Dynamic Analysis and Experimental Study on Permanent Magnet AC Servo Precision Drive System .Chongqing University. 2009.4.P47-63.

[7] Lin lihong,Chen xiaoan,Zhou chaoqun,Zhouwei, Modeling and Simulation analysis on Electromechanical Coupling of Precision Transmission System. Chongqing University (Natural Science) .2007.30 (11) P14-18.

[8] Lin lihong, Chen xiaoan, Zhouwei,Miao yingbin, Electromechanical Coupling Dynamic Analysis Study on Permanent Magnet AC Servo Precision Drive System. Chongqing University (Natural Science) . 2008.7.

[9] Atsumi T,Arisaka T,Shimizu T,et al.Head-positioning control using resonant modes in hard disk drives.IEEE/ASME Transactions on Mechatronics.2005.10(4)P378-384.

DOI: 10.1109/tmech.2005.852445
