Novel Man-Machine Interface of Intelligent Leak Detector for Advanced Material with Material Properties in Fuel-Gas Pipe Based on Electrical Power System

Abstract:

The advanced material has been used extensively in various engineering in recent years, especially in the fuel-gas pipes. The material properties are always under the influence of a variety of factors, such as different levels of the manufacturers, the manufacturing process and so on. Although many countries have strict supervision to the material properties of fuel-gas pipes, but the pipe leak is inevitable. So the leak detection has important meaning in the field test experiment of pipes’ material properties and the practical engineering. In order to solve the problem of interaction between the fuel-gas pipe leak detector and the users, a man-machine interface is designed based on electrical power system. The hardware mainly consists of the microprocessor, the input circuit and the output circuit. The software of interface is realized with the embedded C language, and it mainly consists of the input program and the output program. Experiment results show that the man-machine interface can accomplish the interaction between the user and the detector for advanced material with material properties in fuel-gas pipe splendidly; and it has a good application prospect.

• Periodical: Advanced Materials Research (Volume 676)
• Pages: 293-296
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.676.293
• Online since: March 2013
• Authors: Ling Juan Zhang, Jian Qiang Ren
• Keywords: Advanced Material, Electrical Power System, Fuel-Gas Pipe, Intelligent Leak Detector, Man-Machine Interface, Material Property

References

[1] N. Kamei, H.Watari, T. Hatano, Y. Kawamura. Improvement of local decrease in material thichness of fuel supply pipe. Advanced Materials Research. Vol. 264-265(2011), pp.200-205.

DOI: 10.4028/www.scientific.net/amr.264-265.200

[2] J. B. GAO, Y. GUO, X. F. WANG. Research of Quantitative Risk Analysis Model for Urban Gas Pipeline Network. Journal of Basic Science and Engineering, Vol. 16(2008), pp.280-286.

[3] L. WANG, F. Li. Reliability Assessment of Gas Transmission and Distribution Systems in City. GAS & HEAT, Vol. 25(2005), pp.5-8.

[4] S. J. HE, W. G. ZHOU, M. Q. YAN. Accident Statistics Analysis and Countermeasures for City Gas Transmission and Distribution System. GAS & HEAT, Vol. 23(2003), pp.753-755.

[5] Y. WANG. A Brief Talk of the Laser Fuel Gas Instrumentation under Gas Leaking Circumstance. URBAN GAS. (2008), pp.12-14.

[6] X. M. Gao, H. Fan, T. Huang, and et al. Natural Gas Pipeline Leak Detector Based on NIR Diode Laser Avsorption Spectroscopy. Spectrochimica Acta-Part A: Molecular and Biomolecular Spectroscopy, Vol. 65(2006), pp.133-138.

DOI: 10.1016/j.saa.2005.09.046

[7] J. LI, Y. S. XU, J. J.YU. New Technologies for Leakage Detection of Gas Pipeline. GAS & HEAT, Vol. 27(2007), pp.56-59.

[8] FREESCALE, MC68HC812A4 Data Sheet. Information on http://www.freescale. com.

[9] WAVESHARE. LCD Moudule Specification For Approval: Waveshare LCD1602. Information on http://www.elecfans.com.

[10] X. G. ZHANG. Embedded C Language Program Design: Practical Training Course (Peking University Press, Beijing 2008).
