Finite Element Modal Analysis of Whole Structure of Spherical Grinder

Abstract:

In order to analyze vibration characteristics of whole structure of the spherical grinder, the finite element analysis software is applied to finite element modal analysis of the structure. 3D model of spherical grinder is established by Pro/ENGINEER software. Finite element model of spherical grinder is established in the finite element analysis software ANSYS Workbench. The previous 6-order inherent frequencies and the corresponding vibration modes are obtained through the finite element calculation. According to the vibration intensity distribution, the corresponding improvement measure is put forward. It provides theoretical basis for dynamic analysis and improved design of spherical grinder.
