An Easily Realizable Band-Notched UWB Antenna

Abstract:

An easily realizable ultrawideband (UWB) monopole antenna, with band-notched characteristics, is presented. The antenna consists of a circular metal radiation patch, fed by a 50-Ω microstrip transmission line and a rectangular ground plane with a notch cut into it. By etching a modified U-shaped slot in the radiating patch and by properly tuning its location and form, band-rejected filtering properties can be achieved easily in WiMAX/WLAN bands. It has good omni-directional radiation patterns in H-plane and a good agreement between simulation and measurement.
