A Numerical Study on Block Shear Strength of Channel Four-Bolted Connections Fabricated with Austenitic Stainless Steel

Abstract:

Stainless steel has been utilized on structural members of building due to significant characteristics in its superior corrosion resistance, durability, aesthetic appeal etc. Recently, structural behaviors and curling effect in single shear bolted connection fabricated with thin-walled plane plates have been studied by T.S. Kim. In this paper, finite element analysis (FEA) has been conducted based on the existing test result of channel bolted connections in austenitic stainless steel. The validation of numerical approach was verified to predict the structural behaviors such as fracture mode, ultimate strength and curling occurrence of bolted connections. Curling (out-of- plane deformation) also occurred in the connections with a long end distance like bolted connections assembled with plane plates. The curling caused the ultimate strength reduction and ultimate strength reduction caused by curling has been estimated quantitatively through the comparison of FEA results of FE models with free edge and restrained curling. Additional parametric analysis for FE models with extended variables has been performed. Therefore, the ultimate strengths were compared with current design strengths and reasonable strength formulae for connections with no curling effect were proposed.

• Periodical: Advanced Materials Research (Volume 680)
• Pages: 247-251
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.680.247
• Online since: April 2013
• Authors: Tae Soo Kim, Min Seong Kim, Seung Hun Kim, Yong Taeg Lee
• Keywords: Channel Bolted Connection, Curling, Design Code, Parametric Numerical Analysis, Stainless Steel (SS), Strength Reduction

References

[1] H. Kuwamura, A. Isozaki, J Struct Const Eng (Transactions of Architectural Institute of Japan), 556, (2002) 159–166.

[2] TS Kim, H. Kuwamura, Thin-Wall Struct., 45, (2007) 407–421.

[3] TS Kim, H, Kuwamura, TJ Cho, Thin-Wall Struct., 46, (2008) 38–53.

[4] TS Kim, H. Kuwamura, SH Kim, YT Lee, TJ Cho, Thin-Wall Struct., 47, (2009) 1191–1202.

[5] Xiao-ting Chu, Roger Kettle, Long-yuan Li, J. Constructional Steel Research, 60(8), (2004) 1159-1175.

[6] Osama Bedair, J. Constructional Steel Research, 67(10), (2011) 1415-1425.

[7] T. S Kim, M.S. Kim, S.H. Kim, Y.T. Lee, S.W. Shin, Advanced Materials Research, 255-260 (2011) 74-78.

[8] American Institute of Steel Construction, Steel Construction Manual, AISC, (2011).

[9] European Committee for Standardisation : Design of steel structures : supplementary rules for stainless steels, Eurocode 3 Part 1. 4, (1996).

[10] Architectural Institute of Japan (AIJ), Recommendation for the Design and Fabrication of Light Weight Steel Structures. AIJ, Tokyo, Japan (2002).
