Arbitrary Curvature Radius of the Optical Parts Precision Polishing Technology

Abstract:

This paper puts forward a kind of magnetorheological polishing technology of arbitrary curvature radius spherical optical parts and the mechanical structure of its supporting equipment. By changing the position of the intersection point of the spindle unit and pendulum shaft device in the space, it can achieve high quality and rapid processing of an arbitrary curvature radius of the spherical optical parts. The wheel-head structure of our equipment is an endless belt structure. The magnetorheological fluids are added to the endless belt, and the wheel-head structure 15 is powered. Then, it will form a Bingham on the endless belt with which the surface of the processed optical parts contact. At last, it will achieve precision flexible polishing process ultimately. A simple mechanical structure design and breakthrough processing method are used in the equipment and the complete processing technology, which can achieve flexible polishing of large-diameter spherical (or plane) optical components with any radius. The machining accuracy is less than 1nm, achieving the requirements of the ultra-smooth surface.

• Periodical: Advanced Materials Research (Volume 683)
• Pages: 589-594
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.683.589
• Online since: April 2013
• Authors: Mo Yang, Zhong Da Guo, Zhi Qiang Yang
• Keywords: Arbitrary Curvature Radius, Endless Belt Structure, Magnetorheological, Polishing Technology, Processing of Optical Parts, Surface Contact, Ultra-Smooth Surface

References

[1] Moss T. , Optics manufacturing: It's not the same old grind [J], Photonics Spectra, 1994. (12): 80~92.

[2] Wang Shu-xing, The research of the polishing process of optical parts' fixed abrasive [J], Instrument Manufacturing, 1982. 5. 1: 1~5(in Chinese).

[3] Stowers I F., Komanduri R, Baird E D., Review of precision surface generating processes and their potential application to the fabrication of large optical components [J], Proc of SPIE, 1988. 966: 62~73.

DOI: 10.1117/12.948050

[4] Liu Wei-guo, Guo Zhong-da, Yang Zhi-qiang, Chen Zhi-li, Mi Qian, Hang Ling-xia, Wang Hong-jun, Tian Ai-ling, A processing method of arbitrary curvature radius of the optical parts and its apparatus [P], Chinese patent, CN102765029A, 2012. 11. 7(in Chinese)Chinese patent, CN102765029A [P], 2012. 11. 7.

[5] Shu Chao-lian, Tian Ai-ling, Hang Ling-xia, Guo Zhong-da, Modern optical manufacturing technology [M], National Defence Industry Press, 2008. 5. 1(in Chinese).

[6] Zhou Yan, The analysis of the main factors for affecting the ultra-smooth quality during the classical polishing [J], Chemical Engineering & Equipment 2008. 10: 89~92 (in Chinese).

[7] Yang Zhi-qiang, Guo Zhong-da, Chen Zhi-li, Liu Wei-guo, A method of magnetorheological polishing [J], Applied Optics, 2009. 5. Vol. 30 No. 3：500~504(in Chinese).

[8] Guo Zhong-da, Du Shu-juan, Liu Wei-guo, Hang Ling-xia, Wang Wei, Ring with a magnetic field in magnetorheological polishing technology [J], The journals of Xi'an University of Technology, 2007. 6. Vol. 27 No. 3: 212~214(in Chinese).
