Intelligent Rotor Fault Identification Method Based on HWD Energy Distribution and Grey Relation Degree

Abstract:

In this paper, a novel comprehensive fault identification approach was proposed based on the harmonic window decomposition (HWD) frequency band energy extraction and grey relation degree. Firstly, in order to eliminate the influence of noises, the line structure element was selected for morphological filter to denoise the original signal. Secondly, due to the energy of vibration signal will change in different frequency bands when fault occurs, therefore, the six feature frequency bands which contain the typical fault information were extracted by harmonic window decomposition that need not decomposition; and the energy distribution of each band could be calculated. Finally, these energy distributions could serve as the feature vectors, the grey relation degree of different vibration signals was calculated to identify the fault pattern and condition. Practical results show that this method can identify rotor fault patterns effectively.

• Periodical: Advanced Materials Research (Volume 684)
• Pages: 373-376
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.684.373
• Online since: April 2013
• Authors: Wen Bin Zhang, Yan Ping Su, Ya Song Pu, Yan Jie Zhou
• Keywords: Energy Distribution, Fault Recognition, Grey Relation Degree, Harmonic Window Decomposition, Morphological Filtering, Rotor

References

[1] W. B. Zhang, X. J. Zhou and F. H. Mu. Application of morphological filter in purification of rotor center's orbit, edited by Proceedings of the 2008 1st International Congress on Image and Signal Processing, pp.136-140. (2008)

DOI: 10.1109/cisp.2008.204

[2] W. B. Zhang, X. J. Zhou and Y. Lin. Application of morphological filter in pulse noise removing of vibration signal, edited by Proceedings of the 2008 1st International Congress on Image and Signal Processing, pp.132-135. (2008)

DOI: 10.1109/cisp.2008.202

[3] Y. G. Luo and C. Z. Chen. Diagnostic analysis of grey network in rotary machinery trouble, edited by Compressor Blower & Fan Technology, Vol.4 (2001), pp.38-40.

[4] Y. B. Dong and X. L. Zhang. Determination method for identification coefficient of grey relational grade and applying in mechanical faults diagnosis, edited by Equipment Manufacturing Technology, Vol. 3 (2008), pp.121-122, 125.

[5] Q. Zhao, J. Gao, T. F. Wu and L. Lu. The grey theory and the preliminary probe into information acquisition technology, edited by Proceedings International Conference on Information Acquisition, pp.402-404. (2004)

DOI: 10.1109/icia.2004.1373399

[6] W. B. Zhang, X. J. Zhou and Y. Lin. Refinement of rotor center's orbit by a harmonic window method, edited by edited by Journal of Vibration, Measurement & Diagnosis, Vol. 30(2010), pp.87-90.

[7] W. B. Zhang, X. J. Zhou and X. Y. Yang. Harmonic window method for purification of axis trace, edited by Journal of Vibration and Shock, Vol. 28 (2009), pp.74-77.
