A Study on Co-Simulation for Rotating Mechanism of Bogie Separation Device Based on ADAMS/MATLAB

Abstract:

In the process of bogie separation device operations, rotating system is required to push bogie and settlement beam to rotate . After the completion of bogie wheel replacement and maintenance, they need to be pushed back to original position. This paper explains working principle of rotating mechanism of monorail vehicle bogie separation device and performs co-simulation and analysis of rotating mechanism based on ADAMS/MATLAB. Analysis results show that the rotating hinge mechanism and its proportional control system can completely meet the requirements of the rotary motion.

• Periodical: Advanced Materials Research (Volumes 694-697)
• Pages: 233-236
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.694-697.233
• Online since: May 2013
• Authors: Chun Lei Liu, Guang Sheng Ren
• Keywords: ADAMS/MATLAB, Bogie Separation Device, Proportional Control, Rotating Mechanism, Simulation Modeling

References

[1] Busuan, Guangsheng Ren.Modeling and simulation for hydraulic system of separation device based on AMEsim/simulink (SMSEM2011)

[2] Li Zhe, Kota Sridhar: Virtual prototyping and motion simulation with ADAMS (2001)

[3] Yongtang Li: Hydraulic system modeling and simulation (2003), P.167

[4] Yibei Zhu: Mechanical control engineering foundation (1999), P.123

[5] Zenggang Li: ADAMS detailed introduction and examples (2006), P.200
