Stress Analysis of the Underground Gas Storage Well Stored CNG Based on the Finite Element Method

Abstract:

Currently CNG has been widely used as an automotive fuel, and the security problems about CNG storage well are prominent which poses a serious threat to life and property.This indicates that the safety of the underground gas storage well stored CNG is of great importance. The purpose of this paper is to analyze the section of gas storage well that is the joint of casing and coupling based on the finite element method,as this section is the most dangerous.Using ANSYS software,the stress field of this section will be acquired.An example of a finite element model will be used to demonstrate the main section related to gas storage well failure is the root of the first engaged tooth of a joint between coupling and casing.

• Periodical: Advanced Materials Research (Volume 704)
• Pages: 338-342
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.704.338
• Online since: June 2013
• Authors: Cheng Li Song, Yong Dan
• Keywords: Compressed Natural Gas (CNG), Finite Element Method (FEM), Underground Gas Storage Well

References

[1] Wei Guo.The leakage analysis of gas storage well at CNG filling station.Chemical Engineering & Equipment.2011，39（9）：97-98.

[2] Lin Yang,Zheng Liang,etc.The finite element analysis of CNG gas storage well`s thread.Oil Field Equipment.2008，37（10）:59-62.

[3] Zuzhi Chen,Kun Shi,etc. The design question discussion of gas storage well.Pressure Vessel.2012，29（2）：50-51.

[4] Yongzhang Yu,Qilie Gao,etc.The equipment and operation of CNG filling station for cars.China Petrochemical Press.Beijing.2010:5-35.

[5] GB18047.CNG for cars.China Standards Press.Beijing.2000:1-6.

[6] GB150-2011.Pressure Vessel.China Standards Press.Beijing.2012:3-10.
