Design Optimization of MEMS Based LLC Tunable Resonant Converter for Power Supplies on Chip

Abstract:

In this paper, a novel MEMS based LLC converter is proposed for on chip power supplies. The design is optimized based on commercially available Metal MUMPs process for fabrication. The resonant frequency is optimized at 20MHz and MEMS based variable capacitor is fabricated on the chip to tune the peak resonance frequency of circuit which varies due to the load variations. The Design is simulated in FEM based numerical software COMSOL and Intellisuite. According to analysis the magnetizing inductance of 42nH and leakage inductance of 40nH has been achieved from 16 mm² rectangular coil transformer. The total capacitance of 1500pF has been achieved from parallel plate capacitors and variation of 3pF has been achieved from variable capacitor.

• Periodical: Advanced Materials Research (Volume 705)
• Pages: 258-263
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.705.258
• Online since: June 2013
• Authors: Fahimullah Khan, Yong Zhu, Jun Wei Lu, Dzung Dao
• Keywords: Leakage Inductance, Magnetizing Inductance, Metal MUMPs, Resonant Converter, Tunable Capacitor
