Design and Optimization of Dual-Redundancy Transmission System

Abstract:

According to the special requirements of the redundant input drive system in the aerospace field, a scheme of dual-redundancy transmission system is presented and it meets the requirements that one axis can output movements no matter two input axes are working together or working alone. Based on the analysis of the scheme, structure design scheme is presented, and the matching relationship of gear teeth is derived to meet the requirement of transmission ratio. Then the multidisciplinary design optimization model of the dual-redundancy transmission system is established, in which the system is discomposed into two subsystems: differential gear train and fixed axis gear train. The multidisciplinary variable couple design optimization method of discrete variable is used in the optimal design of dual-redundancy transmission system and the optimal comprehensive scheme is obtained.

• Periodical: Advanced Materials Research (Volumes 706-708)
• Pages: 1258-1261
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.706-708.1258
• Online since: June 2013
• Authors: Bi Qiang Yu, Ming Zhang, Wen Rui Wang
• Keywords: Multidisciplinary Design Optimization, Optimal Design, Redundancy Transmission

References

[1] Bai Zhifu, Han Xianguo, Chen Wuyi. Optmial design of parallel mechanisms with large tilting ability based on redundant actuation . Journal of Beijing University of Aeronautics and Astronautics 2006, 32 (7), pp.856-859

[2] Zhang Kaizhi． Study on dynamic characteristics of redundantly driven revolving system of shield TBM． Shanghai Jiao Tong University．(2011)

[3] Xiong Xinyuan．Key technique research on redundant actuation of the heavy load mechanisms. Hebei University of Technology．2007.

[4] Yu Bi-qiang, Weng Hai-shan, Li Jiang, Qiu Li-fang. Multidisciplinary variable couple design optimization．Journal of university of science and technology Beijing．2007, 29(5), pp.528-531
