Design and Structure Strength Analysis of Double-Deck Prestressed Sectional Female Die

Abstract:

Monolithic die often early failure due to tangential cracking in the production process of the bush by cold extrusion; Derived through theoretical calculations based on the study of the bush forming process technology, a reasonable interference quantity, contact stress, designed to double-deck prestressed sectional female die, established a reasonable boundary conditions of the finite element model; using ANSYS Workbench as a platform, the work process of the double-deck prestressed sectional female die are studied by numerical simulation, preliminary forecast of the distribution of the stress field of the sectional female die in no-load and work process, compared to the working strength of the original monolithic die, verified the superiority of prestressed sectional female die, provided a valuable reference for the actual production.

• Periodical: Advanced Materials Research (Volumes 706-708)
• Pages: 1262-1265
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.706-708.1262
• Online since: June 2013
• Authors: Qing Qing Lv, Li Quan Yang, Lei Zhao
• Keywords: Double-Deck Prestressed Sectional Female Die, Interference Quantity, Nonlinear, Numerical Simulation, Structure Strength

References

[1] S.Z. Zhang: Extrusion technology and die design. Chemical Industry Press, Beijing (2009).

[2] C.S. Yang: Cold extrusion dies design. National Defence Industry Press, Beijing (1994).

[3] L.Q. Yang, L.Z. Yang and Q.Q. Lv: Coal Mine Mach. Vol. 33(2012, 2), pp.65-67.
