Research on the Structure Strength and Vibration Mode of Transformer

Abstract:

To check the reliability of transformer’s strength and vibration mode, we analyze the structure of the transformer, definition the Load condition , process the boundary condition and Create the finite element model . we use ANSYS software to analyze transformer s structure strength and mode, which provides important support to reliable design. From the analysis of above, the structure design and the stiffness of transformer is totally meeting with the requirement of design.
