Dielectric Properties and Microstrip Patch Antenna Performances of 0.95MgTiO₃-0.05CaTiO₃ Microwave Ceramics

Abstract:

τMicrowave dielectric properties of 0.95MgTiO₃-0.05CaTiO₃ ceramics and their performances as H-shaped microstrip patch antenna were investigated. Best values of dielectric constant (ε_r) and quality factor (Q×f) of 19.00 and 66800GHz, respectively, were obtained for the microwave ceramics sintered at 1300°C for 3h. A near-zero temperature coefficient of resonant frequency (τ_f) of -4.7ppm/°C was obtained for the ceramics with sintering 1280°C for 3h. A new kind of H-shaped microstrip patch antenna with two resonant frequencies was fabricated by using of this kind of ceramics as antenna substrate. The return loss bandwidth of the patch antenna was extended with the increasing of substrate thickness at both resonant frequencies of the antennas, around 1.530GHz and 2.750GHz, respectively.

You might also be interested in these eBooks

Mechatronics and Intelligent Materials III

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 706-708)

Pages:

64-68

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.706-708.64

Citation:

Cite this paper

Online since:

June 2013

Authors:

Zhao Xian Xiong, Guo Feng Zhang, Hao Xue, Jin Bao Huang, Qiang Zheng, Bai Qiang You

Keywords:

Bandwidth, Microstrip Patch Antenna, Microwave Ceramics

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] T. Shanmuganantham and S. Raghavan: International Journal of Electronics and Communications Vol. 63 (2009), pp.653-659.

Google Scholar

[2] S. Nomura: Ferroelectrics Vol. 49 (1983), pp.61-70.

Google Scholar

[3] K. Wakino: Ferroelectrics Vol. 91(1989), p.69.

Google Scholar

[4] R.C. Kell, A.C. Greenham, G.C.E. Olds: Journal of the American Ceramic Society Vol. 56 (1973), p.352.

Google Scholar

[5] V.M. Ferreira and J.L. Baptista: Materials Research Bulletin Vol. 29 (1994), pp.1017-1023.

Google Scholar

[6] Y.C. Chen, S.M. Tsao, C.S. Lin, S.C. Wang and Y.H. Chien: Journal of Alloys and Compounds Vol. 471 (2009), pp.347-351.

Google Scholar

[7] Y.J. Wang, W.J. Koh, J.H. Tan, P.T Teo and P.C. Yeo: IEEE Transactions on Antennas and Propagation Vol. 34 (2001), pp.219-222.

Google Scholar

[8] X. Zhao, J.G. Miao and J.S. Jiang: Advanced Materials Research Vol. 433-440 (2012), pp.3525-3530.

Google Scholar

[9] F. Yang, X.X. Zhang and X.N. Ye: IEEE Transactions on Antennas and Propagation Vol. 49 (2001), pp.1094-1100.

Google Scholar

[10] A.A. Abdelaziz: Progress in Electromagnetics Research Vol. 63 (2006), pp.311-317.

Google Scholar
