The Design and Finite Element Analysis for Crane Turntable Gear Based on Pro/E and ANSYS

Abstract:

The use of Pro/E and their respective advantages ANSYS software product design and engineering analysis to solve the case, first of all in the Pro/E, the completion of three-dimensional helical gear design, and then in the Pro/MECHANICA completed finite element model of helical gear, and then into ANSYS for finite element analysis of bevel gear calculation and simulation, finite element analysis of the final results of optimization design model is presented recommendations for improvement. The product design and engineering analysis method has some reference value in engineering design.

• Periodical: Advanced Materials Research (Volume 710)
• Pages: 243-246
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.710.243
• Online since: June 2013
• Authors: Xian Hong Yang
• Keywords: Features, Finite Element, Load, Parameter

References

[1] Xu Guobin. PRO / ENGINNEER Wildfire in the implementation and application [M] Beijing: Mechanical Industry Press, 2003.

[2] Wang Jianjiang, Huren Xi, Liu Yinglin. ANSYS11.0 structure and thermodynamics of finite element analysis instance and guidance materials [M].: Armed Industry Press, 2008.

[3] Zhu Lingyun, Li Bin PRO / ENGINNEER movement simulation and finite element analysis [M] Beijing: People's Posts and Telecommunications Press, 2004.

[4] S·Koekebak ker. Model Based Control of a Flight Simulator Motion System [D]. Delft: Delft University of Technology, 2001.

[5] Zhang Jichun, Xu Bin. Pro / ENGINEER Wildfire structural analysis [M]. Beijing: China Machine Press,(2004)
