Orientation System of Best Imaging Location of Aerial Cameras Based on CCD

Abstract:

A system for orientation the best imaging location of aerial cameras is designed, and the working principle, hardware components of the system are described. The orientation information is produced by collimator. The best imaging location is determined by size of the collecting image with area CCD camera and the data is processed by least square method. The converter controls the translation of the camera in axial direction precisely. Off-focus or not is judged based on the distance between the real image location and the best image location. Through the tests of multiple aerial cameras, the estimation of off-focus or not is similar with test flight result with the system.

• Periodical: Advanced Materials Research (Volume 710)
• Pages: 424-427
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.710.424
• Online since: June 2013
• Authors: Mei Zhao, Ying Zhao, Yu Fang Sha, Fei Guo, Ming Quan Yang
• Keywords: Aerial Camera, Best Imaging Location, CCD Camera, Least-Square Method (LSM), Orientation

References

[1] Datu Su, Liping Zhao and Dingguo Sha. "Optical Testing Technology" Press, 1996.19-20.

[2] Hong Liu, Zhaoshu Liao: Journal of Wuhan Institute of Science And Technology, Vol. 15(5) (2002), p.83. In Chinese.

[3] Yuliang Zhao, Kaiduan Li: Optical Technique , Vol.28(3) (2002), p.204. In Chinese.

[4] Yuliang Zhao, Kaiduan Li and Qingchen Zhang: Aerial Measure and Test Technology, Vol.22(1) (2002), p.10. In Chinese.

[5] Yuliang Zhao, Kaiduan Li: Journal of Transducer Technology, Vol.21(1) (2002), p.51. In Chinese.
